The Honeywell 51153818-101 functions as a configuration jumper kit for the C200 series process controllers. This accessory kit enables engineers to modify input and output signal settings on control modules. Consequently, it provides flexibility for customizing analog and digital channels in distributed control systems.
Technical Specifications and Kit Contents
Instrument technicians require detailed knowledge of jumper configurations for proper system setup. Therefore, we present the complete specifications for the Honeywell 51153818-101:
| Parameter | Specification |
|---|---|
| Manufacturer | Honeywell |
| Product Type | Configuration Jumper Kit |
| Series | C200 Controller Series |
| Compatible Modules | AI, AO, DI, DO, and mixed I/O cards |
| Number of Jumpers | 50 pieces per kit |
| Jumper Types | 2-pin and 3-pin configurations |
| Jumper Pitch | 2.54 mm standard spacing |
| Current Rating | 3 amperes maximum per contact |
| Contact Material | Phosphor bronze with gold plating |
| Insulator Material | High-temperature PBT plastic |
| Dimensions (Package) | 85 mm x 55 mm x 15 mm |
| Weight | 0.05 kg |
| Storage Temperature | -40°C to 85°C |
| Operating Temperature | -40°C to 105°C |
| RoHS Compliance | Yes, lead-free construction |
Jumper Configuration Options
The 51153818-101 kit includes both shunt jumpers for enabling functions and programming jumpers for addressing. Additionally, it provides three-pin jumpers for selecting between multiple signal ranges or termination options. These components allow technicians to configure input types such as voltage, current, or thermocouple on analog modules. You can use these jumpers alongside protection devices like the RMS TSG TZ C static trip unit for comprehensive system configuration. Furthermore, the Honeywell 51153818-101 includes color-coded options for easy visual identification during maintenance.
Installation and Configuration Benefits
This jumper kit eliminates the need for soldering or special tools when reconfiguring I/O modules. Moreover, its gold-plated contacts ensure reliable connections even in high-vibration industrial environments. The 51153818-101 allows rapid field changes without removing modules from the rack. Each jumper features a positive retention mechanism to prevent accidental disconnection during operation. Typical applications include Honeywell C200 analog input cards, digital output modules, and specialized function boards.
Handling and Storage Guidelines
Store the Honeywell 51153818-101 kit in its original anti-static packaging when not in use. Handle jumpers by the insulator body only to avoid contaminating the gold contact surfaces. Verify correct orientation before installing jumpers on module pins to prevent damage. Finally, document all jumper configurations thoroughly for future troubleshooting and system modifications.
Details
| Weight | 0.2 kg |
|---|---|
| Dimensions | 85 × 65 × 30 mm |
