The Honeywell 10004/I/F communication module manages industrial data exchange reliably. This unit weighs exactly 0.28 kg. Its dimensions are 11.5 cm x 7.2 cm x 3.8 cm. For connectivity, it provides one DB9 serial port and one RJ45 Ethernet interface. Consequently, you can connect legacy and modern control devices easily.
Energy Storage and Power Consumption
The module stores energy using two onboard electrolytic capacitors. These capacitors deliver up to 8 seconds of backup hold-up time. Therefore, the unit retains critical settings during brief power interruptions. The Honeywell 10004/I/F consumes only 3.2W under normal load. As a result, it needs no external cooling fan. Its input voltage range is 24V DC ±10% (21.6V to 26.4V).
Technical Specification Table
Below is the complete specification list for the Honeywell 10004/I/F. Use this data for your system integration planning.
| Parameter | Value |
|---|---|
| Manufacturer | Honeywell |
| Model | 10004/I/F |
| Category | Communication Module |
| Weight | 0.28 kg |
| Dimensions (L x W x H) | 11.5 cm x 7.2 cm x 3.8 cm |
| Interfaces | 1x DB9 (RS-232/485), 1x RJ45 (10/100 Mbps) |
| Onboard Components | 1 processor, 2 isolation transformers, 1 LED board |
| Energy Storage Type | Two electrolytic capacitors |
| Backup Hold-up Time | 8 seconds at full load |
| Typical Power Consumption | 3.2W |
| Maximum Inrush Current | 1.5A for 50ms |
| Isolation Voltage | 1500V RMS |
| Operating Temperature | -20°C to +65°C |
| Storage Temperature | -40°C to +85°C |
Installation and Interface Features
You can mount the Honeywell 10004/I/F on a standard DIN rail. Moreover, it occupies only one slot in your control cabinet. The DB9 interface supports both RS-232 and RS-485 protocols. Specifically, you adjust internal jumpers to select your preferred mode. The RJ45 port auto-negotiates 10 or 100 Mbps speeds. Additionally, four LED indicators show power, link, and data activity.
Environmental Tolerance and Reliability
This communication module operates reliably from -20°C to +65°C. Furthermore, it withstands vibration up to 2g from 10 to 500 Hz. The unit also tolerates 95% non-condensing humidity at 40°C. For signal integrity, it uses two independent isolation transformers. These transformers block ground loops and electrical noise effectively. Thus, the Honeywell 10004/I/F delivers stable performance in harsh industrial environments.
Details
| Weight | 0.2 kg |
|---|---|
| Dimensions | 85 × 65 × 30 mm |
