The GE IS200SRLYH2A (also designated as IS200SRLYH2AAA) functions as a simplex relay output module within the Mark VIe control system platform. This component provides reliable switching capabilities for industrial automation and turbine control applications. It therefore enables precise control of external devices like solenoids, indicators, and contactors.
Key Technical Specifications
We engineered the GE IS200SRLYH2A to deliver robust output switching for demanding industrial environments. Its simplex design ensures straightforward integration into existing Mark VIe control architectures.
| Parameter | Specification |
|---|---|
| Product Type | Simplex Relay Output Module |
| Alternate Part Number | IS200SRLYH2AAA |
| Series | Mark VIe Control System |
| Manufacturer | GE |
| Output Channels | Multiple relay output channels |
| Contact Type | Form-A (normally open) relay contacts |
| Contact Rating | Standard industrial relay ratings |
| Switching Voltage | Suitable for AC and DC control circuits |
| Switching Current | Rated for typical pilot duty applications |
| Interface Type | Backplane connector to main control |
| Isolation | Channel-to-channel and coil-to-contact isolation |
| Mounting Style | Rack mount in Mark VIe panel |
| Dimensions (Height) | Standard Mark VIe module height |
| Dimensions (Width) | Single-slot module width |
| Dimensions (Depth) | Standard module depth |
| Weight | Lightweight construction |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Protection Rating | IP20 (requires enclosure installation) |
| Status Indicators | LED per channel for output state |
| RoHS Compliance | Compliant with applicable directives |
Output Configuration and Performance
The GE IS200SRLYH2A provides multiple normally open relay contacts for controlling field devices. Each output channel includes an LED indicator for immediate visual status confirmation. The relay contacts handle typical industrial control voltages and currents reliably.
Isolation and Protection Features
The GE IS200SRLYH2A incorporates optical isolation between the control logic and output relays. This isolation protects the main control system from voltage transients on field wiring. The module consequently maintains reliable operation even in electrically noisy environments.
Installation and Integration Details
The GE IS200SRLYH2A features a compact single-slot design for efficient panel space utilization. Its backplane connector ensures secure communication with the Mark VIe main processor. The module mounts directly into standard Mark VIe racks without special tools.
Details
| Weight | 0.1 kg |
|---|---|
| Dimensions | 25 × 108 × 127 mm |
