The IS200CSLAH4A is a high-speed serial link (HSSL) expander card designed for GE Mark VI Speedtronic systems. It enables ultra-fast fiber optic communication between controllers, supporting EX2100 excitation systems and Mark VI turbine controllers. This module ensures reliable data transfer and supports redundant configurations in complex automation setups.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Model | IS200CSLAH4A |
| Series | Mark VI Speedtronic |
| Product Type | HSSL Expander Card |
| Board Type | Compact PCI Serial Link |
| Communication | Fiber Optic Ethernet |
| Transceivers | Avago HFBR-5961xxZ |
| Board Design | Double-sided components |
| Coating | Conformal protection |
| Revision | A (most common) |
| Compatibility | EX2100, Mark VI controllers |
| Installation | Factory-drilled holes for M1, M2, and C modules |
| Redundant Control | Supported in multi-module setups |
| Dimensions | 160 mm x 100 mm x 15 mm (L x W x H) |
| Weight | 500 g |
| Product Origin | USA |
Key Features
- High-speed fiber optic communication ensures rapid data transfer between modules.
- Supports redundant configurations for M1, M2, and C modules in Mark VI systems.
- Double-sided board design reduces footprint while maintaining performance.
- Compatible with EX2100 excitation systems for turbine control.
- Avago HFBR-5961 transceivers guarantee stable connections.
- Conformal coating provides resistance to humidity and temperature fluctuations.
Applications
The IS200CSLAH4A HSSL expander card functions as an I/O module connecting EX2100 main processors with Mark VI turbine controllers. It is ideal for redundant system setups, enabling continuous data communication and fault-tolerant operation.
Installation Notes
- Installs via factory-drilled holes; does not support standard VME rack mounting.
- Works alongside UCSB and HSLA I/O boards.
- Follow original GE documentation for proper setup and compatibility.
Warranty & Shipping
- Includes a 12-month warranty.
- Ships worldwide via FedEx, UPS, and DHL for fast delivery.
Frequently Asked Questions
Q1: What type of communication does the board support?
A1: High-speed fiber optic Ethernet using Avago HFBR-5961 transceivers.
Q2: Which systems are compatible with this card?
A2: Works with GE EX2100 excitation systems and Mark VI turbine controllers.
Q3: How is the card mounted?
A3: Installs via factory-drilled holes, not standard VME racks.
Q4: Can this card be used in redundant systems?
A4: Yes, it supports M1, M2, and C modules in redundant configurations.
Q5: What does HSSL stand for?
A5: High-Speed Serial Link, enabling fast controller-to-controller communication.
Details
| Weight | 0.5 kg |
|---|---|
| Dimensions | 160 × 100 × 15 mm |
