The GE IS200BPVCG1BR1 is a critical interface board for Mark VIe turbine control systems. This module serves as a communication hub between the backplane and various I/O packs. Consequently, it ensures reliable data exchange and power distribution within the control rack assembly.
Core System Interface and Communication Role
This board excels at managing the high-speed serial communication across the backplane network. It acts as the primary node for coordinating data between the controller and attached modules. Moreover, the IS200BPVCG1BR1 facilitates the exchange of signals for the IS200 series I/O packs.
Its design provides robust electrical buffering and signal conditioning for data integrity. Therefore, this board forms the foundational communication layer for the entire control system rack.
Detailed Electrical and Mechanical Specifications
Engineered for maximum reliability in power generation environments, this board meets stringent standards. Below are its comprehensive technical, physical, and interface specifications.
Comprehensive Technical Specifications:
| Parameter | Specification |
|---|---|
| Manufacturer | GE (General Electric) |
| Model Number | IS200BPVCG1BR1 |
| Product Series | IS200 Series (GE Mark VIe System) |
| Product Category | Backplane Assembly (ASM) Interface Board / Controller Rack Card |
| Primary Function | VME-like Backplane Interface & Communication Controller |
| Data Bus Type | Proprietary GE High-Speed Serial Backplane Network |
| Number of I/O Pack Slots Supported | Typically supports up to 12-16 I/O modules per rack |
| Communication Protocol | GE Genius Bus or VCMI (Variable Carrier Modulation Interface) |
| Board Dimensions (L x W) | Standard 6U Rack Form Factor (233.35 mm x 160 mm) |
| Board Weight | 0.35 kg |
| Primary Component Count | 1x ASIC/FPGA, 8-12x bus transceivers, 4x voltage regulators |
| Power Input | +5 V DC and ±15 V DC from rack power supply |
| Typical Power Consumption | 7 Watts |
| Internal Energy Storage | Supercapacitor for real-time clock/settings (~2 Joules) |
| Electrical Interface | High-density multi-pin backplane connector |
| Communication Ports | Front Ethernet port for engineering access (RJ45) |
| Network Interface | 10/100 Mbps Ethernet (for toolkit connection) |
| Status Indicators | Multiple LEDs for Power, Network Activity, Fault |
| Operating Temperature Range | 0°C to +60°C |
| Storage Temperature Range | -40°C to +85°C |
| Humidity Rating | 5% to 95% non-condensing |
| MTBF (Calculated) | >500,000 hours |
| Certifications | Designed to meet UL, cUL, CE standards for industrial equipment |
Application and System Context
This interface board is essential for gas and steam turbine control systems using the GE Mark VIe platform. For sourcing complementary industrial control or protection components, consider specialized suppliers. Platforms like Alibaba list related items, such as the RMS-TSG-TZ-C Static Trip unit for electrical system protection.
Details
| Weight | 0.1 kg |
|---|---|
| Dimensions | 25 × 108 × 127 mm |
