The HIMA 90900 subrack integrates seamlessly with the HIMA Planar4 System, accommodating up to 20 modules in locations 1–20. Location 21 is reserved exclusively for the communication module.

Key Features

• Fully assembled aluminium chassis with chromated surface ensures durability and safety.
• Rear bus PCB contains socket connectors, soldering strips, and integrated bus structure.
• Connects internal 24 VDC power supply, common busbar, and fault signal loops.
• Includes front labeling field and rear cable duct for organized wiring.
• Supports Ex(i) modules with replaceable connection strips.

Technical Specifications

Bus PCB and Wiring Principles

• EL+ connects through a fuse or circuit breaker rated at 16 A with 2.5 mm² wire cross-section.
• L- reference pole connects from L- distribution bar to terminal blocks XG.1 and XG.6.
• Terminal blocks XG.2 to XG.5 are floating and provide separate supply lines for L+ and L-.
• For fault signal loops, link pins z26–d26 of unused modules to EC terminals.
• Avoid mechanical stress by removing plug terminal blocks before connecting or removing wires.
• Earth connections bond to the subrack’s metal parts for grounding and safety compliance.

Module Installation and Safety Notes

• Use separate supply lines for power outputs to maintain current limits.
• Replace rear connection strips with Ex types if using Ex(i) modules.
• Standard subracks with 32-pole connectors can be used if no external communication is required.

Bus PCB Rear View

​The HIMA 90900 subrack ensures organized installation, reliable power distribution, and flexible module configuration for Planar4 System applications.
