The GE IC698PSA100 provides reliable primary power for GE Fanuc’s PACSystems RX7i automation platforms. Unlike dedicated protection devices such as the RMS-TSG-TZ-C Static Trip Unit from Sie-mens, this unit focuses on converting incoming line power to stable backplane voltages. It supports a wide range of control components including PLC processors and I/O modules. Engineers depend on this supply for consistent performance in demanding industrial environments. This module truly exemplifies GE’s commitment to robust and flexible power management solutions.
Key Technical Specifications
We engineer the IC698PSA100 to deliver regulated DC power from either AC or DC input sources. The following table outlines its core technical parameters for precise system integration.
| Specification | Detailed Value |
|---|---|
| Manufacturer | GE Fanuc / GE Intelligent Platforms |
| Product Type | Power Supply Module |
| Series | PACSystems RX7i |
| Model Number | IC698PSA100 |
| Nominal Input Voltage | 120/240 VAC or 125 VDC (selectable) |
| Input Voltage Range | 85-264 VAC or 100-150 VDC |
| Input Power Rating | 125 Watts total consumption |
| Input Frequency | 47-63 Hz for AC operation |
| Output Voltage +5 VDC | Up to 20 Amps continuous |
| Output Voltage +12 VDC | Up to 2 Amps continuous |
| Output Voltage -12 VDC | Up to 1 Amp continuous |
| Physical Design | Compact, rugged construction for harsh environments |
| Weight | 4.14 lbs (1.88 kg) |
| Category | PLCs / Machine Control |
| Subcategory | PLC Module / Rack |
| Status | Discontinued by Manufacturer (replacement available) |
Flexible AC or DC Input Capability
The primary advantage of the IC698PSA100 lies in its dual-source input flexibility. You can connect it to standard 120/240 VAC mains power or a 125 VDC industrial battery system. Therefore, this module adapts seamlessly to facilities with different power distribution philosophies. The wide 85-264 VAC range also accommodates global voltage standards without manual switching. Consequently, you can use the same power supply for installations in North America, Europe, or Asia.
Triple-Output Design for Comprehensive Power
We designed the IC698PSA100 to provide all necessary voltages for a complete RX7i rack. The +5 VDC output delivers up to 20 amps to power the backplane and digital logic circuits. Additionally, the +12 VDC and -12 VDC outputs supply analog modules and communication interfaces. This triple-output architecture eliminates the need for separate power supplies for different module types. Therefore, you can simplify your panel layout and reduce overall wiring complexity.
Rugged Construction for Industrial Environments
The IC698PSA100 features a compact yet rugged design built to withstand harsh conditions. Its robust enclosure protects internal components from vibration, dust, and temperature extremes. Furthermore, the module includes built-in overload and short-circuit protection for all output rails. These features ensure reliable operation even in steel mills, automotive plants, and chemical processing facilities. You can confidently install this power supply in the most demanding industrial applications.
Important Discontinuation Notice
Please note that the manufacturer has officially discontinued the IC698PSA100 model. However, GE continues to support the RX7i series with newer power supply alternatives. We recommend contacting our technical sales team for compatible replacement options. They can help you select a current-model power supply that meets your specific voltage and current requirements. This ensures your system continues operating with full manufacturer support and warranty coverage.
