Core Function and System Role
The GE IC698CRE030 serves as a high-performance redundant CPU for critical automation systems. This module, part of the RX3i PACSystem series under Emerson, ensures continuous process operation. Consequently, it provides seamless automatic switchover during a primary CPU failure. Therefore, it delivers the ultimate reliability for applications demanding zero downtime.
Processing Power and Memory
This CPU module features a powerful Pentium-M processor running at 600 MHz. Furthermore, it is equipped with a substantial 64 MB of battery-backed user memory. This combination supports the execution of complex control strategies and data handling. Moreover, the integrated 10/100 Mbps Ethernet port enables high-speed plant network communication.
Detailed Technical Specifications
Designed for mission-critical applications, this CPU meets rigorous industrial standards. The following table details its comprehensive hardware and performance parameters.
| Parameter | Specification |
|---|---|
| Manufacturer / Brand | Emerson Automation (formerly GE Fanuc) |
| Model Number | IC698CRE030 |
| Product Series | RX3i PACSystem Redundant Controller |
| Product Category | Programmable Automation Controller (PAC) CPU |
| Processor Type | Intel Pentium-M |
| Processor Speed | 600 MHz |
| User Memory Capacity | 64 MB |
| Memory Type | Battery-backed SRAM for program and data |
| Primary Network Interface | 10/100 Mbps Ethernet (auto-sensing) |
| Redundancy Protocol | High-speed dedicated redundancy link (fiber optic) |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Approximate Weight | 1.33 kg (2.94 lbs) |
| Power Consumption | Typically 10-15 Watts (varies with configuration) |
| Backup Battery | Lithium battery for memory retention (user-replaceable) |
| Module Dimensions | Standard double-width RX3i form factor |
| Status Indicators | Comprehensive LEDs for status, fault, and network activity |
| Certifications | Complies with major industrial safety and EMC standards |
Redundant Architecture and Diagnostics
The CPU establishes a dedicated, high-speed fiber-optic link with its partner module. This link constantly synchronizes memory and control state between the primary and standby units. Moreover, an extensive suite of LED indicators provides immediate visual health diagnostics. For protecting the entire system’s power integrity, a component like the RMS-TSG-TZ-C static trip unit is essential.
Application and Value Proposition
The GE IC698CRE030 is ideal for industries like power generation, oil & gas, and water treatment. Its redundant architecture safeguards against unplanned production stops and data loss. Choosing this genuine PACSystem CPU ensures full compatibility with the extensive RX3i I/O ecosystem. Ultimately, it provides a future-proof control platform for your most critical processes.
Details
| Weight | 0.1 kg |
|---|---|
| Dimensions | 25 × 108 × 127 mm |
