High-Performance Rack-Mount CPU for Industrial Automation
The IC698CPE010 from Emerson (formerly GE Fanuc) delivers high-speed processing for RX7i PACSystem platforms. Its 300 MHz Intel Celeron processor ensures reliable performance for complex industrial control applications.
Technical Specifications
| Feature | Specification |
|---|---|
| Brand | Emerson (formerly GE Fanuc) |
| Model | IC698CPE010 |
| Series | PACSystem RX7i |
| Type | Rack Mount Central Processing Unit |
| Processor | Intel Celeron 300 MHz |
| User Memory | 10 MB battery-backed RAM |
| Flash Memory | 10 MB non-volatile storage |
| Boolean Speed | 0.33 ms per 1000 contacts/coils |
| Discrete I/O | 32K bits capacity |
| Analog I/O | 32K words capacity |
| Program Blocks | 512 maximum, 128 KB each |
Communication Ports & Protocols
- Ethernet Ports: 2 × RJ-45, 10/100 Mbps with auto-negotiation.
- Serial Ports: 2 × RS-232/RS-485, 1 × RS-232 Station Manager.
- Supported Protocols: Modbus TCP, SRTP, EGD, Modbus RTU.
- Redundancy: Controller supports Media Redundancy Protocol and LAN3 synchronization.
Power Requirements
- Operating Voltage: 5–12 V DC
- Current Draw: 4.5 A @ +5V, 0.042 A @ +12V, 0.008 A @ -12V
- Backplane Current: 3.4 A maximum
- Power Consumption: 22.5 W typical
Programming & Software
- Supported Languages: Ladder Diagram, C, Structured Text, Function Block
- Software: Proficy Machine Edition v4.0+
- Floating Point: Supported
- Web Services: FTP and built-in web server
- Maximum Connections: 16 simultaneous
Physical Specifications
- Mounting: RX7i rack, requires slot 1
- Architecture: VME64 backplane standard
- Compatibility: Series 90-70 I/O modules, VME-based modules
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
Shipping, Warranty & Support
- Warranty: 12 months against manufacturing defects
- Shipping: FedEx, UPS, DHL Express available
- Packaging: Industrial protective packaging
- Lead Time: Typically ships within 24–48 hours
Product Origin, Dimensions & Weight
- Origin: United States
- Dimensions: 180 mm × 130 mm × 50 mm
- Weight: 1.2 kg
Compatibility Information
- RX7i backplane and baseplate systems
- Series 90-70 I/O modules
- VME64 compatible modules
- Proficy Machine Edition software
- Various HMI and communication devices
Details
| Weight | 1.2 kg |
|---|---|
| Dimensions | 180 × 130 × 50 mm |
