This interface module combination provides seamless connectivity for industrial control architectures. It belongs to the GE Drive Systems 6800 series, a product line known for robust motion control applications. The DS6800CCID1D1D/DS6815PCDP1B1A works in conjunction with the DS6800CCID1D1D/DS6815PCDP1B1A to form a complete communication solution.
Technical Specifications
Engineers will appreciate the modular design that separates control and power functions. The assembly includes both the controller interface and the power conversion driver. Together, these components manage signal routing and power distribution for drive systems.
| Parameter | Specification |
|---|---|
| Product Type | Interface Module Set |
| Series | GE Drive Systems 6800 |
| Part Numbers | DS6800CCID1D1D/DS6815PCDP1B1A |
| Module Count | Two modules per set |
| DS6800CCID1D1D Dimensions | Approximately 10.0 in x 4.5 in (254 mm x 114 mm) |
| DS6815PCDP1B1A Dimensions | Approximately 8.5 in x 6.0 in (216 mm x 152 mm) |
| Combined Weight | 4.2 lbs (1.91 kg) |
| Key Components | Microprocessors, memory ICs, power transistors, capacitors |
| Energy Storage | Bulk capacitors maintain stable voltage during load transients |
| Connectors | Multiple high-density ribbon and power connectors |
Design and Configuration
The DS6800CCID1D1D/DS6815PCDP1B1A serves as the primary controller interface within the drive system. It handles command processing and communication with the main control network. Meanwhile, the DS6800CCID1D1D/DS6815PCDP1B1A manages power conversion tasks and gate drive signals.
This pairing allows for flexible system configuration across various motor control applications. The modules interconnect through dedicated backplane slots within the drive chassis. Furthermore, each board features diagnostic LEDs for immediate status indication.
Application and Compatibility
These modules integrate directly into GE Drive Systems 6800 series cabinets. They support a range of industrial motor control applications from simple speed regulation to complex positioning tasks. The DS6800CCID1D1D communicates with host controllers while the DS6815PCDP1B1A drives the power section.
Emerson now supports the legacy GE Drive Systems product line with continued service options. This interface module set provides a reliable solution for maintaining existing drive system installations.
Details
| Weight | 0.1 kg |
|---|---|
| Dimensions | 25 × 108 × 127 mm |
