Product Overview and Core Functionality
The GE IC693PBS105 functions as a central processing unit for the versatile Series 90-30 PLC platform. This module executes control programs, processes I/O data, and manages communication for automated systems. It delivers reliable performance for a wide range of industrial applications.
Engineers design this CPU specifically for medium-scale automation tasks in manufacturing and process control. The GE IC693PBS105 executes ladder logic and function block programs efficiently. Consequently, it provides flexible programming options for diverse application requirements.
Memory and Processing Specifications
The GE IC693PBS105 incorporates substantial memory for both program storage and data handling. It features integrated RAM for executing control logic and holding variable data. Non-volatile memory retains your program during power outages without requiring a battery.
The processor handles boolean logic at impressive speeds for time-critical applications. It scans I/O and executes user programs within predictable timeframes. This deterministic behavior suits high-speed machine control applications perfectly.
Communication Ports and Interfaces
The GE IC693PBS105 features built-in communication ports for programming and operator interface connectivity. A dedicated RS-232 port allows direct connection to a programming computer. An additional serial port supports connections to HMIs using SNP or RTU protocols.
Power Requirements and Physical Specs
The GE IC693PBS105 draws operating power directly from the Series 90-30 rack backplane. It requires +5 VDC at typical current levels for full functionality. The module weighs approximately one pound and fits in a single rack slot.
Front-panel LED indicators provide immediate visual feedback on CPU operating status. You can quickly assess run mode, fault conditions, and activity at a glance. This simplifies troubleshooting during system startup and maintenance.
Environmental and Diagnostic Features
The GE IC693PBS105 operates reliably from 0 to 60 degrees Celsius in industrial environments. Built-in diagnostic functions continuously monitor the health of the CPU and associated systems. The module detects and reports hardware faults for quick response.
Technical Specifications Summary
| Specification | Detail |
|---|---|
| Manufacturer | GE Fanuc / GE Automation |
| Part Number | IC693PBS105 |
| Product Type | CPU Module |
| Series | Series 90-30 |
| Communication Ports | RS-232, SNP/RTU support |
| Power Requirement | +5 VDC from backplane |
| Mounting | Single-slot rack |
| Weight | Approx. 1.0 lb (0.45 kg) |
| Operating Temperature | 0°C to 60°C |
| Status Indicators | Run, fault, communication LEDs |
Details
| Weight | 0.1 kg |
|---|---|
| Dimensions | 25 × 108 × 127 mm |
