The GE IC693CPU372 functions as a powerful central processing unit for Series 90-30 programmable logic controllers. This module integrates Ethernet connectivity directly on the CPU for streamlined networking. It operates at a processor speed of 133 MHz for fast program execution. The IC693CPU372 includes 120 KB of user logic memory for complex control applications. Engineers benefit from the built-in 10/100 Mbps Ethernet port for seamless integration.

Technical Specifications and Physical Characteristics

Precise technical specifications enable proper selection of the GE IC693CPU372 for control system requirements. The module’s robust design supports demanding industrial automation applications with reliable performance.

Advanced Processing Capabilities

The IC693CPU372 delivers exceptional processing power for the Series 90-30 platform. Its 133 MHz clock speed enables rapid execution of complex control algorithms. Boolean logic executes in just 0.37 milliseconds per thousand instructions. This performance suits high-speed applications requiring fast scan times. The 120 KB user memory accommodates substantial program logic and data storage. Engineers can implement advanced functions including floating-point math and PID control.

Integrated Ethernet Communication

Built-in Ethernet eliminates the need for separate communication modules in many applications. The GE IC693CPU372 supports 10/100 Mbps operation with auto-negotiation capabilities. This flexibility ensures compatibility with both legacy and modern network infrastructure. The RJ45 connector provides convenient access using standard Ethernet cabling. Multiple protocols run simultaneously for versatile connectivity options. SRTP protocol enables seamless communication with other GE devices. Modbus TCP support allows integration with third-party HMIs and SCADA systems.

Memory and Data Retention Features

The IC693CPU372 incorporates comprehensive memory management for reliable operation. User programs store securely in internal Flash memory without battery support. A lithium battery maintains register data and real-time clock operation during power loss. This battery typically provides two years of data retention under normal conditions. The CPU supports up to 32768 register words for data handling requirements. Timers and counters total 4096 elements for extensive sequencing applications.

Seamless Integration with Series 90-30 Systems

Engineers integrate the IC693CPU372 easily into existing Series 90-30 racks and systems. The module occupies two slots in the backplane due to its enhanced functionality. It communicates with I/O modules through the rack backplane efficiently. Similar to protection devices like the RMS TSG TZ C Static Trip unit, this CPU ensures reliable system operation. The 4096 discrete I/O capacity handles substantial machine and process applications. Analog I/O support reaches 512 inputs and 512 outputs for continuous control.

Application Versatility in Industrial Automation

The IC693CPU372 suits a wide range of industrial control applications effectively. Common uses include material handling, packaging machinery, and process control systems. Built-in Ethernet simplifies connection to plant-wide monitoring systems. The fast processor supports high-speed applications like assembly machines and sortation systems. Engineers appreciate the combination of power and integration in a single module. This CPU represents a cost-effective solution for mid-sized control applications.
