The GE IC200MDD843 combines digital input and output functions in a single, compact VersaMax module. This discrete mixed module integrates ten sourcing inputs with six high-current outputs for efficient space utilization. Consequently, it provides a cost-effective I/O solution for controlling small machines or compact control panels.
Core I/O Configuration and Electrical Ratings
This module actively monitors ten 24VDC positive logic (sourcing) input points. Moreover, it controls six solid-state outputs capable of switching up to 8 amps each. Therefore, you can directly drive sizable loads like solenoid valves, contactor coils, or indicator lamps without additional relays. The module’s fast 10 ms response speed ensures timely control for most industrial applications.
Detailed Technical Specifications
The table below provides the complete technical and mechanical specifications for this mixed I/O module.
| Parameter | Specification |
|---|---|
| Manufacturer | GE Fanuc (Now Emerson Automation) |
| Full Part Number | IC200MDD843 |
| Product Line | VersaMax PLC & I/O System |
| Module Type | Discrete Mixed I/O Module |
| Total I/O Points | 16 |
| Number of Inputs | 10 |
| Input Type | 24 VDC Positive Logic / Sourcing |
| Number of Outputs | 6 |
| Output Type | Solid-State DC (Sourcing) |
| Output Current Rating | 8 A per point (Maximum) |
| Maximum Total Output Current | Limited by module/rack power budget |
| Response Speed | 10 ms (Maximum) |
| Primary Power Source | Rack-Mounted Backplane (+24VDC) |
| Auxiliary Power Support | Yes (for high-current outputs) |
| Module Weight | 0.50 lbs (0.23 kg) |
| Bulletin/Series | IC200 (VersaMax) |
| Form Factor | Single-Width VersaMax I/O Module |
| Operating Temperature | 0°C to 60°C (Standard) |
| Connector Type | Removable screw-terminal block |
| Status Indicators | LED per I/O point (Typical) |
| Isolation | Channel-to-channel and field-to-logic (Typical) |
| Mounting | VersaMax I/O Rack or Stand-alone Bus Interface Unit |
