The GE IC200CHS022 functions as a Compact box-style I/O carrier module within the VersaMax platform from Emerson Automation. This carrier was originally designed by GE Intelligent Platforms (GE IP) for industrial I/O applications. We stock this essential carrier to support your existing VersaMax installations. It accommodates field wiring with 36 terminals arranged in three convenient strips.

Technical Specifications and Physical Characteristics

Understanding the exact specifications of the GE IC200CHS022 ensures proper integration into your VersaMax control system. This compact carrier features a robust box-style design with clearly labeled terminal points.

Terminal Wiring Specifications and Connection Details

The GE IC200CHS022 provides flexible wiring options for various field device connections. Its terminal design accommodates both single and dual wire configurations for installation convenience.

• Single Wire Size: You can use solid or stranded copper wire from AWG #14 to AWG #22. The average cross-section ranges from 0.36 mm² to 2.1 mm² for these connections.

• Dual Wire Connection: Each terminal accepts two AWG #18 wires for implementing terminal shorting. This feature simplifies daisy-chaining of common signals between multiple points.

• Wire Type: The carrier accepts only copper wire for reliable electrical connections. This ensures consistent conductivity and long-term terminal integrity.

• Terminal Identification: Clearly marked A and B designations simplify wiring and troubleshooting. Therefore, technicians can quickly identify connection points during installation.

• Connection Security: Screw-type terminals provide reliable vibration-resistant connections. This ensures continuous operation in industrial environments.

Electrical Ratings and Current Capacity

The GE IC200CHS022 handles substantial voltage and current for VersaMax I/O applications. Its robust design accommodates both AC and DC signals within specified limits.

• Voltage Rating: The carrier accepts 0 to 264 V AC across all terminals. This wide range suits global industrial power systems and control voltages.

• Current per Point: Each individual terminal supports up to 2 Amperes continuous current. Consequently, it drives moderate loads without external interposing relays.

• Power Terminal Rating: Power and ground terminals handle up to 8 Amperes each. This supports higher current requirements for field device power distribution.

• Ground Current: The ground segment accommodates 8 Amperes continuous current. This ensures adequate return path capacity for connected devices.

• Transient Voltage: The GE IC200CHS022 withstands transient voltages up to 300 V AC. This protects connected I/O modules from momentary power system disturbances.

Physical Construction and Environmental Specifications

The GE IC200CHS022 features durable construction suitable for industrial control cabinets. Its compact design conserves panel space while providing ample termination points.

• Housing Material: The carrier uses high-temperature thermoplastic for the housing. This material resists deformation and maintains terminal spacing under load.

• Terminal Material: Nickel-plated brass terminals resist corrosion and provide low resistance. Therefore, connections remain reliable over many years of service.

• Operating Temperature: The carrier functions from 0 to 60 degrees Celsius. This range suits most indoor industrial control environments.

• Storage Temperature: It withstands storage from -40 to 85 degrees Celsius. This tolerance accommodates shipping and warehouse conditions.

• Humidity Rating: The module operates at 5% to 95% relative humidity without condensation. This protects against moisture-related insulation degradation.

System Integration and Applications

Integrating the GE IC200CHS022 into your VersaMax system requires straightforward mounting and wiring. It works alongside other modules like the IS200AEBMG1AFB in broader GE automation architectures.

• Mounting Method: The carrier mounts directly to DIN rail or panel surface. Integral mounting feet provide secure attachment in high-vibration environments.

• Module Compatibility: It accepts standard VersaMax I/O modules for various signal types. These include discrete, analog, and special function modules.

• Field Wiring: Terminal access remains available after module installation. Therefore, you can modify wiring without removing adjacent components.

• Marking Area: A designated area accepts terminal labeling for circuit identification. This simplifies maintenance and reduces wiring errors over time.

• Spacing Requirements: The GE IC200CHS022 requires minimal clearance between adjacent carriers. This enables high-density I/O installations in crowded cabinets.
