The GE Fanuc IC698PSD300 Power Supply Module provides dependable 300W output for RX7i PACSystem racks. Designed for high-performance industrial automation, it delivers consistent 24V DC power with advanced thermal and electrical protection. Its copper input terminals, integrated diagnostics, and forced-air cooling ensure stable operation even in demanding control environments.
Key Features
- Delivers stable 24V DC output with 300W capacity
- Supports RX7i PACSystem racks with slot-0 mounting design
- Includes built-in airflow monitoring and LED diagnostics
- Protects against overload, over-temperature, and short circuits
- Uses copper input terminals for secure and durable connections
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | GE Fanuc |
| Model Number | IC698PSD300 |
| Series | RX7i PACSystem |
| Power Rating | 300 Watts |
| Output Voltage | 24V DC |
| Inrush Current | 100A maximum |
| Isolation Voltage | 250V AC continuous / 1500V AC for 1 minute |
| Cooling Method | Forced air, 70 CFM airflow |
| Operating Temperature | 0°C to 60°C (32°F–140°F) |
| Mounting Position | Slot 0, left side of RX7i rack |
| Input Terminals | Copper, front access type |
| Protection Features | Over-temperature, overcurrent, short circuit, ground fault |
| Monitoring | Airflow sensor and status LEDs |
| Warranty | 12 months standard |
Installation and Compatibility
The IC698PSD300 module mounts in Slot 0 of the RX7i PACSystem rack, ensuring proper power distribution across all connected modules. It requires adequate forced-air cooling and grounding for safe operation. Users can easily connect copper input terminals for secure installation. The module supports full compatibility with all RX7i system components and ensures reliable communication with the CPU and I/O modules.
Safety and Performance
The GE Fanuc IC698PSD300 integrates multiple protection mechanisms, including automatic shutdown during temperature or current overload. Its airflow sensor continuously monitors fan performance, while diagnostic LEDs offer immediate fault status updates. These features enhance system reliability and minimize downtime in industrial automation environments.
Origin, Dimensions, and Weight
- Country of Origin: USA
- Dimensions: 330 mm × 90 mm × 160 mm (H × W × D)
- Weight: Approximately 1.8 kg
Shipping and Delivery
Each IC698PSD300 module is carefully packaged for safe transport and global shipment through FedEx, DHL, or UPS. We provide full tracking and insured delivery to ensure your order arrives securely and on time.
Details
| Weight | 1.8 kg |
|---|---|
| Dimensions | 330 × 90 × 160 mm |
