High-Precision Output for Complex Control
The GE Fanuc IC697VAL314 delivers exceptional analog control within the Series 90-70 PLC platform. This module provides four independent, software-configurable output channels. Each channel can produce either a precise voltage or current signal to command field devices.
Intelligent Isolated Channel Architecture
The module features complete channel-to-channel and channel-to-logic isolation. This design prevents ground loops and protects the control system from field-side electrical noise. Consequently, it ensures signal integrity and reliable operation in harsh industrial environments.
Detailed Technical Specifications
The table below provides the complete electrical and physical specifications for the IC697VAL314.
| Specification | Detail |
|---|---|
| Manufacturer & Model | GE Fanuc IC697VAL314 |
| Product Series | Series 90-70 PLC |
| Module Type | Isolated Analog Output Module |
| Number of Channels | 4 |
| Output Types | Software-Selectable per Channel |
| Voltage Output Range | 0 to +10 VDC |
| Current Output Range | 4 to 20 mA |
| Output Resolution | 12-bit |
| Isolation Rating | Channel-to-Channel & Channel-to-Logic |
| Voltage Output Load | 1000 Ohms minimum |
| Current Output Load | 0 to 850 Ohms |
| Update Time per Channel | 4.5 ms |
| Power Consumption | +5 VDC from backplane |
| Module Width | Double-Slot |
Flexible Configuration and Diagnostics
Users configure each channel independently via the PLC programming software for voltage or current mode. The module includes comprehensive diagnostics to monitor for open-circuit conditions on current loops. This capability allows for proactive maintenance and ensures continuous process control.
Ideal for Demanding Process Applications
The IC697VAL314 is perfect for driving critical process devices like control valves, variable frequency drives, and servo controllers. Its high isolation and dual-output capability make it a versatile and trusted component for complex automation in industries like chemical processing, water treatment, and power generation.
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 273.6 × 214.1 × 59.2 mm |
