Reliable External DC Power for Industrial Automation
The GE Fanuc IC697PWR721 delivers 90W of DC power for Series 90-70 PLC systems. Its external installation provides flexible system configuration for industrial automation applications.
Key Features and Benefits
- Nominal 24V DC input with a 21–32 VDC operating range
- Maximum output power of 90W with three regulated voltage rails
- Overvoltage limit 6–7 volts protects connected devices
- Shock resistance up to 15 G for 11 milliseconds ensures reliability
- Compatible with GE IC697 racks using a Power Supply Adapter (PSA)
- External installation allows flexible placement in control cabinets
- Operating temperature range from 0 to 60°C supports industrial environments
Output Specifications
| Output Voltage | Maximum Current | Notes |
|---|---|---|
| +5 VDC | 16.5 A | Primary logic power output |
| +12 VDC | 1.5 A | Secondary output for modules |
| -12 VDC | 1 A | Negative supply for logic |
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | GE Fanuc |
| Series | Series 90-70 |
| Model | IC697PWR721 |
| Module Type | DC Power Supply Module |
| Nominal Input Voltage | 24 VDC |
| Input Voltage Range | 21–32 VDC |
| Maximum Input Power | 156 Watts |
| Output Power | 90 Watts Maximum |
| Inrush Energy | 22 J at 32 VDC |
| Voltage Regulation | +5V, +12V, -12V |
| Overvoltage Limit | 6–7 Volts |
| Operating Temperature | 0–60°C |
| Shock Resistance | 15 G for 11 milliseconds |
| Installation Requirement | Requires Power Supply Adapter (PSA) module |
| Compatibility | GE IC697 racks and VME integrated racks |
Dimensions, Weight, and Origin
- Form Factor: External DC power module
- Dimensions: 160 mm × 100 mm × 60 mm
- Weight: Approximately 0.7 kg
- Origin: Manufactured by GE Fanuc, USA
Installation Guidelines
Connect the IC697PWR721 via cable to a Power Supply Adapter (PSA) module. The PSA routes power to the rack backplane. Ensure proper placement for flexible system configuration.
Package Contents
- 1 × GE Fanuc IC697PWR721 power supply module
- User manual
Shipping and Warranty
Ships worldwide via FedEx, UPS, or DHL. Includes a 12-month manufacturer warranty for repair or replacement.
Details
| Weight | 0.7 kg |
|---|---|
| Dimensions | 160 × 100 × 60 mm |
