GE Fanuc IC697MDL640 125V DC Input Module Overview
The GE Fanuc IC697MDL640 is a high-performance 125V DC discrete input module for Series 90-70 PLCs. Furthermore, it provides 16 input points organized into 4 isolated groups. In addition, the module supports both positive and negative logic operations, enabling flexible industrial control applications.
Key Features
- 16 discrete input points in 4 isolated groups for safe operation
- Wide input range from -35 V to 145 V DC for versatile applications
- Supports positive and negative logic for flexible signal processing
- Input current of 5 mA at rated voltage ensures reliable detection
- Requires 0.3 A for module operation from DC power
- Mechanical keys prevent incorrect module installation
- Additionally, user-configurable settings eliminate the need for physical jumpers
- Compatible with Windows-based and MS-DOS programming software
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | GE Fanuc / GE Intelligent Platforms |
| Series | Series 90-70 |
| Model | IC697MDL640 |
| Product Type | Discrete Input Module |
| Logic Type | Positive/Negative |
| Rated Voltage | 125 V DC |
| Input Voltage Range | -35 to 145 V DC |
| Number of Inputs | 16 points (4 isolated groups) |
| Input Current | 5 mA at rated voltage |
| Module Current Required | 0.3 A |
| Power Type | DC Power |
| LED Indicators | None |
| Installation | SNP port or Ethernet TCP/IP connection |
| Configuration | Windows-based or MS-DOS software |
| Mechanical Keying | Prevents incorrect installation |
Package Contents
- One (1) GE Fanuc IC697MDL640 125V DC input module
- Complete installation guide and documentation
Installation Guidelines
First, install the IC697MDL640 into the Series 90-70 PLC rack slot. Next, connect your DC input devices according to the isolated group assignments. Additionally, align the mechanical key carefully to prevent incorrect installation. Finally, configure the module using Windows or MS-DOS software for optimal operation.
Ideal Applications
The IC697MDL640 module is perfect for:
- High-voltage DC signal monitoring in industrial automation systems
- Connecting switches, sensors, and relay contacts with positive/negative logic
- Applications requiring isolated input groups for safe and reliable operation
- Flexible PLC integration via SNP or Ethernet TCP/IP ports
Frequently Asked Questions
Q: What voltage does this module operate at?
A: The module operates at 125 V DC for high-voltage input applications.
Q: How many input points does it have?
A: It provides 16 discrete input points in 4 isolated groups.
Q: Does it support both positive and negative logic?
A: Yes, it supports both positive and negative logic operations for flexible control.
Q: Are there LED indicators for each point?
A: No, this module does not include LED indicators.
Origin, Dimensions, and Weight
- Origin: USA
- Dimensions: 130 mm × 95 mm × 25 mm
- Weight: 0.47 kg
Details
| Weight | 0.47 kg |
|---|---|
| Dimensions | 130 × 95 × 25 mm |
