The GE IC693CMM321 delivers versatile network connectivity for industrial control systems. This module serves as an Ethernet Interface for the reliable Series 90-30 PLC platform from GE Fanuc. It provides multiple communication ports to bridge controllers with enterprise networks and devices. Consequently, system integrators can seamlessly integrate their automation layer with supervisory systems for enhanced data visibility.

Engineered for robust industrial communication, this module supports both client and server operations. Moreover, its built-in status indicators offer clear visual diagnostics for network health. Operators can therefore quickly troubleshoot connection issues and maintain optimal system uptime. The IC693CMM321 is a proven solution for modernizing legacy Series 90-30 systems with Ethernet capability.

Detailed Technical Specifications

The IC693CMM321 offers connectivity defined by its port configuration and protocol support. For full compatibility, always verify requirements with the official GE Fanuc documentation for the Series 90-30.

Technical Specifications:

• Manufacturer: GE Fanuc (Emerson)

• Product Type: Ethernet Interface Module

• Product Line: Series 90-30 PLC

• Part Number: IC693CMM321

• Module Width: Single Slot

• Physical Weight: 0.50 lbs (0.23 kg)

• Total Communication Ports: Three (3)

• Port 1: One (1) RS-232, RJ-11 (Station Manager Port)

• Port 2: One (1) RS-485, 15-pin D-type (Software Loader Port)

• Port 3: One (1) AAUI Port (Primary Network Port)

• LED Indicators: Four (4) – OK, LAN, SER, STAT

• Max Server Connections: Supports up to Sixteen (16)

• Device Operation: Supports both Client and Server modes

• CPU Compatibility: Requires CPU version 6.50 or higher for full functionality

• Accessories: Requires AAUI Cable and External Transceiver for network connection

Design and Integration Features

This module acts as a communication gateway, slotting directly into the Series 90-30 PLC rack. The AAUI network port connects to the plant Ethernet via an external transceiver. The serial ports then provide alternative pathways for programming, configuration, or legacy device connections. This multi-port design offers exceptional flexibility for various system architectures and migration paths.

Furthermore, the module contains no internal energy storage, such as batteries or supercapacitors. It draws all operational power directly from the reliable Series 90-30 backplane. Additionally, the four LED indicators give instant feedback on module status and network activity. These features make the IC693CMM321 a dependable and easy-to-maintain component for achieving industrial networking goals with a trusted PLC platform.
