Industrial drive systems need stable and clean DC power. The GE DS200TCPSG1AME delivers reliable voltage conversion for drive control circuits. This board functions as a TCPS series power supply unit from GE. It provides essential DC power for Mark V and similar drive systems.
Technical Specifications & Dimensions
This board converts AC input to multiple regulated DC outputs. The table below outlines its core technical parameters.
| Parameter | Specification |
|---|---|
| Input Voltage | 115V AC or 230V AC (selectable) |
| Input Frequency | 47 to 63 Hz |
| Output Voltage 1 | 24V DC at 2.5A |
| Output Voltage 2 | 5V DC at 5.0A |
| Output Voltage 3 | ±15V DC at 1.0A |
| Total Power Rating | 85 Watts maximum |
| Efficiency | 82% typical at full load |
| Unit Weight | 0.68 kg (1.50 lbs) |
| Board Dimensions | 220 x 170 x 35 mm |
| Number of Components | 4 transformers + 12 capacitors + 8 diodes |
Construction and Interface Layout
This board features a flame-retardant PCB with a metal heat sink plate. Such a design dissipates heat efficiently during high load operation. Furthermore, the GE DS200TCPSG1AME provides multiple connectors for power distribution. You will find one 6-pin input header and three output headers on this board. The PCB includes test points for voltage verification. An LED indicator shows the presence of the main 24V output.
Energy Storage and Power Regulation
Unlike simple linear supplies, this switching power supply uses bulk storage capacitors. The board features two 1000µF capacitors for 24V output smoothing. Consequently, the GE DS200TCPSG1AME maintains stable voltage during transient load changes. A PWM controller regulates the switching frequency at 100 kHz. This controller achieves high efficiency across a wide load range. The board does not contain any user-replaceable batteries.
Installation and Mounting Requirements
Installing the GE DS200TCPSG1AME requires careful alignment with the drive chassis. The board mounts onto standoffs inside the drive cabinet. It also connects to the backplane via a 24-pin edge connector. Always disconnect all AC power before removing or installing this board. The unit uses passive cooling through the attached heat sink. This design eliminates fan noise and mechanical failures. The board occupies a dedicated power supply bay in the rack.
Integration with Drive Control Systems
This power supply works seamlessly with GE Mark V and DC2000 drive systems. It powers logic circuits, I/O modules, and communication boards. Operators can monitor output voltages using the front panel test points. The GE DS200TCPSG1AME also provides over-voltage and short-circuit protection. Consequently, this board remains essential for legacy drive repairs. The unit delivers consistent performance across a 0°C to 50°C temperature range.
