The GE DS200LRPAG1AGF operates as a LAN receive panel module within the Mark V turbine control series. General Electric designed this board to handle fiber optic communication signals. It receives and processes data from remote panels for coordinated system operation.
Technical Specifications
This module features a fiber optic interface for high-integrity data transmission. The board measures approximately 8.5 inches in width and 5.2 inches in height. It weighs around 0.9 kilograms, making it suitable for rack-mounted installations.
| Specification | Detail |
|---|---|
| Manufacturer | General Electric (GE) |
| Model | DS200LRPAG1AGF |
| Category | LAN Receive Panel Module |
| Series | Mark V (Speedtronic) |
| Interface | Fiber optic receiver |
| Dimensions | 8.5 in x 5.2 in x 1.2 in (approx.) |
| Weight | 0.9 kg (approx.) |
| Components | Optical receiver module, signal conditioning circuits |
Fiber Optic Communication Design
The board uses an optical receiver module to convert light signals into electrical data. This conversion ensures noise-free communication across long cable runs. Fiber optic media eliminates electrical interference that commonly affects copper wiring. Consequently, the GE DS200LRPAG1AGF provides reliable data transfer in electrically noisy environments.
The module supports high-speed data reception for real-time control applications. It synchronizes with the main processor to maintain consistent system timing. Engineers can rely on this board for critical turbine control communications.
Component Layout and Signal Processing
Signal conditioning circuits prepare incoming data for the main control board. The layout includes several integrated circuits for decoding and error checking. Each component serves a specific function within the receive path. Moreover, the GE DS200LRPAG1AGF incorporates diagnostic LEDs for quick status verification.
These status indicators show power availability and active data reception. Technicians can troubleshoot communication issues without opening the rack. This design simplifies maintenance and reduces system downtime.
Integration with Mark V Systems
This LAN receive panel module mounts directly into Mark V control racks. It interfaces with the main processor through dedicated backplane connections. Installation follows standard procedures for Speedtronic series components. The GE DS200LRPAG1AGF provides essential communication capabilities for Mark V turbine control systems.
Details
| Weight | 0.1 kg |
|---|---|
| Dimensions | 25 × 108 × 127 mm |
