The GE DS200FSAAG1ABA is a critical Field Supply Amplifier Board designed for industrial drive systems. It provides stable power amplification and signal conditioning for connected field devices. This module ensures reliable operation within the broader GE Mark Vie turbine control series.
Robust Design for Demanding Environments
This board withstands the rigorous conditions of power generation and heavy industry applications. Its robust construction manages electrical noise and thermal stress effectively. Engineers specifically designed the DS200FSAAG1ABA for seamless integration into existing drive racks. Therefore, it maintains system integrity and supports continuous operational uptime.
Detailed Technical Specifications
The following table outlines the precise technical parameters of the GE DS200FSAAG1ABA board.
| Specification Category | Detail |
|---|---|
| Manufacturer & Series | GE (General Electric) – DS200 Series |
| Board Model | DS200FSAAG1ABA |
| Primary Function | Field Supply Amplifier / Signal Conditioning Board |
| Board Dimensions | Standard 6U form factor for drive system chassis (exact mm in datasheet) |
| Approximate Weight | 0.45 kg (1 lb) — consult official documentation for precise value |
| Electrical Interface | Multiple high-density connectors for power and signal I/O |
| Power Requirements | Typically derives power from the DS200 backplane (+5V, ±15V) |
| Key Components | Contains operational amplifiers, voltage regulators, and filtering networks |
| Channel Count | Designed to condition and amplify multiple analog field input channels |
| Compatibility | Direct replacement part for Mark Vie Speedtronic turbine control systems |
Core Functionality and System Role
The board amplifies low-level analog signals from sensors like transducers and thermocouples. It then conditions these signals for accurate processing by the system’s main controller. This precise signal integrity is crucial for monitoring speed, temperature, and pressure. Consequently, the DS200FSAAG1ABA plays a vital role in protecting expensive turbine assets.
Integration and Maintenance Value
Installing this genuine GE board ensures compatibility and performance in your Mark Vie system. It connects directly to the system backplane via its designated slot. Technicians can perform maintenance or replacement with standard ESD procedures. Ultimately, using the DS200FSAAG1ABA supports reliable long-term system operation and data accuracy.
