The GE DS200DMCBG1AJE serves as a dual processor board within the Speedtronic Mark V turbine control system. This component handles critical control algorithms for gas and steam turbine applications. GE engineered this board to deliver redundant processing capabilities for enhanced system reliability.
Processing Architecture and Memory Configuration
This board incorporates dual processors working in parallel for continuous operation. Therefore, it maintains seamless control even if one processor encounters an issue. The GE DS200DMCBG1AJE utilizes onboard memory modules for storing control parameters and fault logs.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Model | DS200DMCBG1AJE |
| Category | DUP Processor Board |
| Series | Speedtronic Mark V |
| Board Type | DMCB (DOS DUP Processor Board) |
| Processors | Dual microprocessor configuration |
| Component Count | Over 150 discrete components |
| Connectors | 2 x 34-pin, 1 x 20-pin, test points |
| Energy Storage | Capacitor array for power conditioning |
| Weight | Approximately 1.20 lbs (0.54 kg) |
| Dimensions | 10.5 x 7.2 x 1.5 inches |
Component Layout and Power Management
The GE DS200DMCBG1AJE contains a dense arrangement of integrated circuits, resistors, and capacitors. These components work together to execute complex turbine control algorithms efficiently. Moreover, the onboard capacitor array provides stable power conditioning during fluctuating load conditions.
Interface Configuration and Connectivity
This board features multiple connector points for comprehensive system integration. Two 34-pin connectors handle primary communication with other Mark V modules. A 20-pin connector manages auxiliary I/O functions and external device communication. Additionally, test points allow technicians to verify signal integrity during troubleshooting.
Physical Characteristics
Measuring approximately 10.5 inches in length and 7.2 inches in width, this board occupies a standard Mark V slot. It weighs roughly 1.20 lbs, making it manageable for installation and removal procedures. The robust construction ensures reliable performance in industrial turbine environments.
System Integration
This processor board belongs to the Speedtronic Mark V product family. It integrates seamlessly with other Mark V components for complete turbine control solutions. Consequently, operators can maintain consistent system performance across the entire control architecture. The GE DS200DMCBG1AJE represents a critical component for legacy GE turbine systems requiring dependable processing power.
Details
| Weight | 0.1 kg |
|---|---|
| Dimensions | 25 × 108 × 127 mm |
