Industrial drive systems need clear operator feedback and status indication. The GE 531X306LCCBFM1 delivers reliable display interfacing for drive control panels. This card functions as a display interface board from GE. It supports various DC drive models and control cabinets.
Technical Specifications & Dimensions
This card handles LCD display signals and keypad interface functions. The table below outlines its core technical parameters.
| Parameter | Specification |
|---|---|
| Display Type | LCD character or graphic |
| Interface Protocol | Parallel data bus |
| Backlight Supply | 5V DC or 12V DC |
| Keypad Inputs | 8 matrix scan lines |
| Logic Supply | 5V DC from backplane |
| Current Consumption | 150 mA typical |
| Status Indicators | 4 onboard LEDs |
| Unit Weight | 0.22 kg (0.48 lbs) |
| Board Dimensions | 160 x 100 x 18 mm |
| Number of Components | 2 controllers + 6 capacitors + 10 resistors |
Construction and Interface Layout
This board features a fiberglass PCB with gold-plated edge fingers. Such a design ensures reliable contact with the main drive board. Furthermore, the GE 531X306LCCBFM1 provides a 14-pin header for LCD connection. You will also find a 10-pin ribbon connector for keypad input. The board includes four jumpers for display configuration settings. An onboard potentiometer adjusts the LCD contrast level.
Energy Storage and Signal Processing
Unlike simple display adapters, this card includes a dedicated LCD controller chip. The board uses small capacitors for backlight power filtering. Consequently, the GE 531X306LCCBFM1 provides stable voltage to the display module. A shift register handles the keypad scanning function independently. This design offloads display tasks from the main drive processor. The board does not require any battery backup for operation.
Installation and Mounting Requirements
Installing the GE 531X306LCCBFM1 requires careful alignment with the drive chassis. The card plugs directly into a dedicated socket on the main board. It also secures with two plastic standoffs for stability. Always disconnect all drive power before inserting or removing this card. The unit uses passive cooling through natural convection. This design eliminates fan noise and moving parts. The card occupies a vertical position near the drive front panel.
Integration with Drive Control Systems
This display card works seamlessly with GE DC2000 and DC300 drive systems. It shows parameters, fault codes, and diagnostic information to operators. Users can navigate menus using the connected keypad. The GE 531X306LCCBFM1 also supports multiple language character sets. Consequently, this card remains essential for drive operator interface repairs. The unit delivers consistent performance across a 0°C to 50°C temperature range.
Details
| Weight | 0.1 kg |
|---|---|
| Dimensions | 25 × 108 × 127 mm |
