The 5136-PFB-VME from GE Fanuc Emerson functions as a intelligent Profibus master/slave interface card for VMEbus systems. Engineers use this module to connect VME-based controllers directly to Profibus DP networks seamlessly. It handles high-speed data exchange with drives, remote I/O, and third-party devices. This card delivers reliable fieldbus connectivity for industrial automation and process control applications.
Core Processor Architecture and Performance
The 5136-PFB-VME utilizes an Intel 32-bit i960 RISC processor for fast protocol handling and data management. This powerful processor offloads communication tasks from the main VMEbus CPU effectively. It ensures consistent network performance even under heavy data traffic conditions. Consequently, the module maintains precise timing for time-critical Profibus communications.
Memory Configuration and Storage Capacity
This interface card includes 512 KB of flash memory for firmware storage and configuration parameters. The flash memory allows for easy field upgrades as new protocol features become available. Additionally, the module provides battery-backed RAM for maintaining network parameters during power cycles. This non-volatile storage ensures reliable startup without reconfiguration requirements.
Interface Specifications and Connectivity
The 5136-PFB-VME supports all standard Profibus baud rates from 9.6 kbaud to 12 Mbaud automatically. It includes a 9-pin D-Sub connector for direct connection to the Profibus network. Front panel LED status indicators provide immediate visual feedback on card and network status. Furthermore, the module offers electrical isolation for protection against ground loops.
Technical Specifications
| Specification | Detail |
|---|---|
| Manufacturer | GE Fanuc Emerson |
| Product Type | Profibus Interface Card |
| Series | 5136 Series |
| Model | 5136-PFB-VME |
| Bus Type | VMEbus |
| Processor | Intel 32-bit i960 RISC |
| Memory | 512 KB Flash |
| Protocol Support | Profibus DP master/slave |
| Baud Rates | 9.6 kbaud to 12 Mbaud |
| Connector | 9-pin D-Sub |
| Status Indication | LED indicators |
| Isolation | Yes (bus to VME) |
| Form Factor | 6U VME |
| Operating Temperature | 0 to 60°C |
Installation and Integration Benefits
The 5136-PFB-VME plugs directly into any standard 6U VMEbus backplane with simple configuration. Its front panel LEDs enable rapid troubleshooting of network and module status. Users can integrate this card with existing VME-based control systems easily. Therefore, it provides a cost-effective path to Profibus connectivity for legacy VME platforms.
Details
| Weight | 0.1 kg |
|---|---|
| Dimensions | 25 × 108 × 127 mm |
