The GE 369-HI-R-M-0-0-0 functions as a multifunctional motor management relay designed to protect and control critical motor assets in industrial applications. This versatile relay accepts wide-range control power from 50-300 VDC or 60-265 VAC at 50/60 Hz, making it suitable for global installations with varying power infrastructures. Engineers select the 369 series for comprehensive motor protection, metering, and diagnostic capabilities in a single integrated unit.
Advanced Protection and Monitoring Features
We equip the GE 369-HI-R-M-0-0-0 with twelve built-in RTD inputs for comprehensive thermal monitoring of motor windings, bearings, and driven equipment. The optional metering package provides real-time measurement of voltage, current, power, and energy consumption for complete motor oversight. Enhanced diagnostics with the enhanced faceplate deliver detailed event recording and fault analysis, enabling predictive maintenance strategies and reducing unplanned downtime.
Control Power: Accepts 50-300 VDC or 60-265 VAC, 50/60 Hz for global compatibility.
RTD Inputs: 12 built-in inputs for stator, bearing, and ambient temperature monitoring.
Metering Package: Optional module providing comprehensive electrical measurements.
Diagnostics: Enhanced features with advanced faceplate for detailed system analysis.
Protocol Options: Configuration supports future expansion with optional interfaces.
Physical Specifications and Application Versatility
The 369-HI-R-M-0-0-0 measures approximately 22.9 cm in height, 18.4 cm in width, and 14.7 cm in depth, featuring a panel-mount design for control room or motor control center installation. The unit weighs roughly 3.2 kg and incorporates modular terminal blocks for secure field wiring connections. This configuration excludes fiber optic ports, protocol interfaces, and harsh environment options, providing a cost-effective solution for standard industrial environments.
Technical Specifications Overview
| Parameter | Specification |
|---|---|
| Manufacturer | GE Multilin |
| Part Number | 369-HI-R-M-0-0-0 |
| Product Type | 369 Motor Management Relay |
| Control Power | 50-300 VDC / 60-265 VAC, 50/60 Hz |
| RTD Inputs | 12 (built-in) |
| Metering Package | Optional – included |
| Fiber Optic Port | None (0) |
| Protocol Interfaces | None (0) |
| Harsh Environment Option | None (0) |
| Diagnostics | Enhanced with Enhanced Faceplate (E) |
| Dimensions (HxWxD) | ~22.9 cm x 18.4 cm x 14.7 cm |
| Weight | ~3.2 kg |
| Mounting | Panel mount |
Configuration Breakdown
369: Base motor management relay unit
HI: High-range control power supply (50-300 VDC / 60-265 VAC)
R: 12 RTD inputs for thermal monitoring
M: Optional metering package for electrical measurements
0: No fiber optic port
0: No protocol interfaces
0: No harsh environment coating
E: Enhanced diagnostics with enhanced faceplate
Details
| Weight | 0.595 kg |
|---|---|
| Dimensions | 18 × 225 × 209.7 mm |
