This digital output card provides high-density control for industrial automation systems. It integrates seamlessly with the FUJI Micro-X series PLC platform. Engineers rely on this module for reliable switching of actuators and indicators.
Technical Specifications & Mechanical Data
The FUJI NV1Y32T05P1 features thirty-two discrete output points for flexible system configuration. Each output channel delivers up to 0.5A of continuous current at 24V DC. The transistor output type ensures fast response times for precision applications.
| Parameter | Specification |
|---|---|
| Model | FUJI NV1Y32T05P1 |
| Category | Digital Output Card / PLC Module |
| Output Points | 32 points (sink type) |
| Rated Load Voltage | 24V DC |
| Max Load Current | 0.5A per point |
| Output Type | Transistor (sink) |
| Response Time | 1 ms or less |
| Internal Power Consumption | 150 mA (5V DC) |
| Dimensions (W x H x D) | 50 mm x 90 mm x 75 mm |
| Weight | Approximately 0.25 kg |
Design and Integration
This output card connects directly to the Micro-X series backplane for simplified installation. The module uses a single 40-pin connector for all field wiring interfaces. Its compact housing allows for high-density mounting within control cabinets.
Moreover, the NV1Y32T05P1 includes built-in surge suppression for extended component lifespan. Operators can easily monitor each output status through visible LED indicators on the front panel. This design simplifies troubleshooting during routine maintenance.
Performance and Reliability
The card dissipates heat efficiently, eliminating the need for additional cooling mechanisms. It stores no user data independently, relying instead on the CPU module for configuration. For similar industrial control components, manufacturers often recommend matching this card with compatible power supplies to ensure stable operation. The FUJI design philosophy prioritizes long-term reliability in demanding environments.
Details
| Weight | 0.7 kg |
|---|---|
| Dimensions | 2.5 × 20.3 × 15.2 mm |
