This compact PLC module combines processing power with built-in I/O capabilities. It belongs to the FUJI NP4N series, offering an all-in-one solution for small automation systems. Engineers choose this unit for space-constrained applications requiring reliable logic control.
Technical Specifications & Mechanical Data
The FUJI NP4N-IPAC integrates a CPU core with discrete input and output channels on a single chassis. Its compact housing eliminates the need for separate base boards in smaller installations. The module provides sufficient memory for handling medium-complexity control programs.
| Parameter | Specification |
|---|---|
| Model | FUJI NP4N-IPAC |
| Category | PLC Module / Integrated CPU Controller |
| Input Points | 8 points (24V DC) |
| Output Points | 6 points (transistor, sink type) |
| Program Capacity | 8K steps |
| Internal Memory | 8KB (RAM) |
| Processing Speed | 0.5 μs per basic instruction |
| Rated Supply Voltage | 24V DC |
| Power Consumption | 15 W (maximum) |
| Dimensions (W x H x D) | 120 mm x 90 mm x 75 mm |
| Weight | Approximately 0.65 kg |
| Communication Interface | RS-232C programming port |
Design and Integration
This integrated unit eliminates the complexity of selecting separate CPU and I/O modules. It mounts directly onto a DIN rail or panel for straightforward installation. Consequently, system assembly becomes faster and cabinet space usage reduces significantly.
Furthermore, the NP4N-IPAC features a built-in programming port for easy configuration and monitoring. Operators can connect a programming device directly to the front panel interface. This design simplifies commissioning and troubleshooting during system startup.
Performance and Reliability
The module operates without requiring external cooling fans due to its efficient thermal design. It stores user programs reliably in internal memory with battery backup for data retention. For industrial control applications, FUJI engineers designed this compact PLC to deliver dependable performance in limited-space environments.
