The FUJI FSB110H functions as a backplane board for Fuji Electric Micro-Series programmable controller systems. Fuji designed this component for mounting CPU and I/O modules in compact automation configurations. This unit establishes the electrical backbone for small-scale control applications.
Module Mounting Capacity
This backplane board accommodates multiple modules within a compact footprint. It provides dedicated slots for secure CPU and I/O module installation. Therefore, users can build space-efficient control systems for distributed automation tasks.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Fuji Electric |
| Model | FSB110H |
| Category | Backplane Board |
| Series | Micro-Series |
| Component Count | Backplane traces, module connectors, mounting hardware |
| Connectors | Module connectors, power input terminals |
| Weight | Approximately 0.85 lbs (0.39 kg) |
| Dimensions | 7.2 x 4.8 x 1.2 inches |
| Mounting | DIN rail or panel mount |
Backplane Architecture
The FUJI FSB110H integrates a backplane for distributing power and communication signals. It routes data between the CPU and connected I/O modules reliably. Moreover, the compact design maintains signal integrity within limited physical space.
Power Distribution
This backplane distributes power to all installed modules through dedicated pathways. It accepts external power input through terminal connections. Consequently, modules receive consistent voltage levels without individual wiring requirements.
Physical Characteristics
Measuring approximately 7.2 inches in length, this backplane fits into confined control cabinets. It weighs roughly 0.85 lbs for straightforward mounting and installation. The rigid construction ensures proper alignment for module insertion and secure retention over time.
Interface Configuration
This backplane features module connectors for accepting Micro-Series CPU and I/O components. Each connector provides both power and signal pathways for seamless system integration. Additionally, the power input terminals simplify field wiring by consolidating external connections.
System Integration
This backplane belongs to the Fuji Micro-Series programmable controller product family. It supports CPU modules, digital I/O, and analog I/O for flexible configuration options. The FUJI FSB110H provides essential infrastructure for facilities requiring compact Micro-Series control systems with reliable backplane communication.
Details
| Weight | 0.7 kg |
|---|---|
| Dimensions | 2.5 × 20.3 × 15.2 mm |
