The FUJI NP1L-UC1 functions as an SX bus communication module for FUJI POD and operator interface systems. This module enables seamless communication between FUJI HMIs and various PLC networks. Engineers use it to connect operator terminals with multiple controller brands and protocols. The NP1L-UC1 provides reliable data exchange for industrial automation applications. Its compact design integrates easily into existing control panel layouts.
Technical Specifications
| Specification | Details |
|---|---|
| Product Type | SX Bus Communication Module |
| Series | FUJI POD / Operator Interface |
| Part Number | NP1L-UC1 |
| Communication Protocol | SX Bus (Proprietary FUJI Protocol) |
| Compatible Devices | FUJI POD, HMI, PLC Systems |
| Transmission Speed | 38.4 kbps Maximum |
| Transmission Distance | 200 meters Maximum |
| Network Topology | Multi-Drop Bus |
| Connected Units | Up to 32 Devices per Network |
| Isolation | 500 Vdc Between Communication and Logic |
| Module Width | 60 mm |
| Height | 100 mm |
| Depth | 70 mm |
| Weight | 0.25 kg |
| Power Supply | 24 Vdc from Host Device |
| Power Consumption | 2 W Maximum |
| Connection Type | Terminal Block and RJ45 |
| Internal Components | Communication Processor, Isolation Circuits |
| LED Indicators | Power, Communication Active, Error |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -20°C to 70°C |
Communication Capabilities
The NP1L-UC1 implements the FUJI SX bus protocol for reliable data exchange. It supports multi-drop network configurations with up to 32 connected devices. Transmission distances reach 200 meters for flexible system layouts. The module operates at 38.4 kbps for efficient data transfer. Engineers build distributed operator interface systems with this communication module.
Integration with FUJI Systems
FUJI NP1L-UC1 integrates seamlessly with FUJI POD and HMI operator terminals. It connects directly to the host device through internal system connections. The module handles all SX bus communication tasks independently. This offloads communication processing from the main HMI processor. Engineers achieve faster display response and more reliable operation.
Physical Design and Installation
The NP1L-UC1 features a compact form factor for space-constrained control panels. Its small footprint allows installation in crowded enclosures easily. Terminal blocks accept field wiring for network connections securely. RJ45 connectors provide convenient connection for pre-assembled cables. LED indicators show power, communication activity, and error status clearly. Engineers monitor network operation at a glance without special tools.
Network Configuration and Setup
The NP1L-UC1 simplifies network configuration with automatic parameter detection. It recognizes network speed and settings from the host device automatically. Engineers set node addresses through simple switch settings on the module. The module supports both master and slave configurations for system flexibility. Similar to protection devices like the RMS TSG TZ C Static Trip unit, this module ensures reliable communication.
Application Versatility
The NP1L-UC1 suits various industrial automation applications effectively. Common uses include production line monitoring, machine control interfaces, and process visualization. Multiple HMIs connect on the same SX bus for distributed operator stations. The module supports data exchange between operator terminals and PLC systems. Engineers use it to build cost-effective operator interface networks.
Related System Components
The NP1L-UC1 works with other FUJI SX bus related modules for complete system solutions. These components include additional communication interfaces and network accessories. Engineers select appropriate modules for specific application requirements. The modular approach allows system expansion without replacing existing components.
Details
| Weight | 0.7 kg |
|---|---|
| Dimensions | 2.5 × 20.3 × 15.2 mm |
