Overview of the FBM201 Analog Input Module
The Foxboro P0914SQ FBM201 module processes multiple analog signals accurately, and it supports demanding industrial automation applications. It handles current-loop sensor inputs reliably, and it maintains stable performance across wide temperature and humidity ranges. Engineers choose this module when they need consistent measurement quality and durable field performance.
Input Capability and Signal Handling
The FBM201 module manages eight independent analog channels, and it accepts 0–20 mA DC sensor signals. It ensures precise acquisition through stable input conditioning, and it works effectively with standard industrial transmitters. Additionally, the module offers strong environmental tolerance, which protects signal integrity in harsh plants.
Technical Specifications
| Specification | Details |
|---|---|
| Model | P0914SQ / FBM201 |
| Number of Channels | 8 analog input channels |
| Input Signal Range | 0–20 mA DC |
| Operating Temperature | -20°C to +60°C (Compact FBM201) |
| Termination Assembly Temperature | -20°C to +70°C |
| Operating Humidity | 5% to 95% noncondensing |
| Altitude Rating | -300 to +3,000 m |
| Storage Temperature | -40°C to +85°C |
| Storage Humidity | 5% to 95% noncondensing |
| Storage Altitude | -300 to +12,000 m |
| Environmental Classification | ISA S71.04 Class G3 (Harsh) |
| Vibration Rating | 7.5 m/s² (0.75 g), 5–500 Hz |
| Module Weight | 185 g (Compact FBM201) |
| TA Weight – Compression | 181 g |
| TA Weight – Ring Lug | 249 g |
| Height | 130 mm |
| Width | 25 mm |
| Depth | 150 mm including connectors |
Physical Design and Environmental Strength
The P0914SQ FBM201 module offers a compact form factor, and it fits easily into dense control cabinets. Its rugged enclosure tolerates vibration and airborne contaminants effectively, which ensures long-term reliability in chemical, power, and refining plants. It also operates consistently across high-altitude installations, and it maintains full measurement accuracy under extreme environmental stress.
Origin, Dimensions, and Weight
- Origin: United States
- Dimensions: 130 mm × 25 mm × 150 mm
- Weight: 185 g (module)
Application Scenarios
Automation engineers install the Foxboro FBM201 module in distributed control systems that require precise analog acquisition. It manages transmitter outputs in flow, pressure, and temperature loops, and it supports fast installation through compact termination assemblies.
Details
| Weight | 0.185 kg |
|---|---|
| Dimensions | 130 × 25 × 150 mm |
