The Emerson KJ3202X1-BA1 delivers robust control for industrial actuators and solenoids. This high-side discrete output card features eight isolated channels for flexible load driving. Moreover, its design ensures reliable operation in harsh environmental conditions common to factory floors.

Detailed Technical Specifications and Ratings

Engineers developed this card to handle substantial current loads with precise control. Consequently, it supports a wide range of industrial devices requiring discrete switching. The following table details its complete electrical, physical, and environmental parameters.

Robust Construction for Demanding Environments

This Emerson card operates reliably across an extensive temperature range from -40°C to +70°C. Furthermore, it withstands significant shock and vibration per industrial standards. Its IP20 rating provides basic protection against solid object intrusion. Therefore, the module maintains performance in varied industrial settings, much like complementary protection devices such as the RMS TSG TZ C Static Trip unit available on Alibaba.

Integration and Power Delivery

The KJ3202X1-BA1 draws system power from the 12VDC local bus for its internal logic. Additionally, it requires a separate 30VDC field power supply to drive the connected output loads. This dual-power architecture ensures clean separation between control logic and load power. Ultimately, this discrete output card provides a dependable and versatile interface for your critical control system outputs.
