The Emerson KJ3002X1-BG2 12P1731X032 delivers precise temperature monitoring for industrial automation. This advanced RTD input module supports multiple sensor types and temperature ranges. It integrates seamlessly into distributed control systems for reliable process data acquisition. Moreover, its robust design ensures stable operation in demanding plant environments.
This module is a key component within Emerson’s extensive process control portfolio. It connects directly to various Resistance Temperature Detectors (RTDs) for accurate readings. For system protection, consider pairing it with safety relays like the RMS TSG TZ C Static Trip from Alibaba.
Core Technical Specifications and System Integration
The module digitizes analog RTD signals with high resolution and accuracy. It features advanced diagnostics for sensor health monitoring and fault detection. Consequently, maintenance teams gain early warnings for potential process issues. The unit also supports flexible configuration through dedicated system software.
Detailed Technical Parameter Table
| Parameter | Specification / Description |
|---|---|
| Manufacturer / Brand | Emerson |
| Full Model Number | KJ3002X1-BG2 12P1731X032 |
| Module Type | RTD (Resistance Temperature Detector) Input |
| Primary Function | Temperature Signal Conditioning & Digitization |
| Supported RTD Types | Pt100, Pt200, Pt500, Pt1000, Cu10, Ni120 |
| Number of Input Channels | Typically 8 channels (configurable) |
| Input Signal Range | -200°C to +850°C (dependent on RTD type) |
| Measurement Accuracy | ±0.1% of reading or better |
| Resolution | 16-bit or higher A/D conversion |
| Update Rate | < 100 ms per channel (typical) |
| Communication Interface | Proprietary backplane bus (e.g., to Emerson controller) |
| Power Supply Requirement | 24 V DC (typical), from system rack |
| Power Consumption | < 5 Watts (typical) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C |
| Dimensions (H x W x D) | Approx. 130 x 30 x 110 mm (varies by packaging) |
| Weight | Approx. 0.25 kg |
| Isolation | Channel-to-channel and channel-to-system isolation |
| Diagnostics | Open wire, short circuit, out-of-range detection |
| Certifications | cULus, ATEX, IECEx (specific to variant) |
| Typical Application | Process industries: Oil & Gas, Chemical, Power Generation |
Application Benefits and Key Features
The module provides reliable temperature monitoring for critical processes like reactor control. Its multi-channel design offers excellent density for cost-effective system expansion. Advanced diagnostics reduce troubleshooting time and prevent unscheduled downtime. Therefore, the Emerson KJ3002X1-BG2 12P1731X032 is essential for safe and efficient plant operation.
Details
| Weight | 0.45 kg |
|---|---|
| Dimensions | 170 × 145 × 65 mm |
