The KJ3002X1-BF1 12P1732X082 is a 12-channel RTD input module for Emerson’s DeltaV system. This module accurately measures temperature from connected Resistance Temperature Detectors. Furthermore, it delivers high-resolution data essential for precise process control and monitoring.
High-Performance Signal Acquisition
Engineered for demanding industrial environments, this module provides excellent measurement accuracy and speed. Its fully isolated inputs effectively protect the signal from electrical noise and ground loops. Consequently, the module ensures data integrity for critical temperature monitoring applications.
Detailed Technical Specifications
The table below details the core technical parameters of this Emerson DeltaV module.
| Parameter | Specification | |
|---|---|---|
| Manufacturer & Series | Emerson | DeltaV System |
| Module Model | KJ3002X1-BF1 12P1732X082 | |
| Module Type | RTD (Resistance Temperature Detector) Input Module | |
| Number of Channels | 12 | |
| Input Signal Type | RTD | |
| Measurement Range | -200°C to +850°C | |
| Measurement Resolution | 16 bits | |
| Measurement Accuracy | ±0.1% of Reading | |
| Sampling Rate | 100 samples per second | |
| Channel Isolation Voltage | 1500 V | |
| Operating Temperature Range | -40°C to +70°C | |
| Operating Humidity Range | 0 to 95% (Non-condensing) | |
| Primary Function | High-Density, High-Accuracy Temperature Input |
Application in Process Industries
You integrate this module into DeltaV systems for reliable temperature measurement across various points. It is ideal for industrial automation, complex process control, and equipment condition monitoring. The module’s wide operating range and robust design support continuous operation in challenging plant environments.
Details
| Weight | 0.2 kg |
|---|---|
| Dimensions | 150 × 100 × 50 mm |
