The KJ3001X1-BJ1 12P0555X152 is an 8-channel digital input module for Emerson’s DeltaV system. This compact unit seamlessly integrates into the control chassis, providing versatile signal interface capabilities. Moreover, its optical isolation ensures reliable operation and robust protection for connected field devices.
Versatile Signal Interface and Diagnostics
This module accommodates various signal types including dry contacts, solid-state outputs, and voltage inputs. Each channel features clear LED indicators for real-time status and diagnostic monitoring. Consequently, technicians can quickly identify field wiring issues or process faults.
Detailed Technical Specifications
The table below lists the essential technical parameters for this Emerson DeltaV digital input module.
| Parameter | Specification | |
|---|---|---|
| Manufacturer & Series | Emerson | DeltaV System |
| Module Model | KJ3001X1-BJ1 12P0555X152 | |
| Module Type | Digital Input Module | |
| Number of Channels | 8 | |
| Channel Isolation | Optical Isolation | |
| Supported Input Types | Dry Contact, Solid-State, Voltage | |
| Typical Voltage Ranges | 0-24 VDC, 0-120 VAC (Confirm with specific datasheet) | |
| Status Indicators | Per-Channel LEDs & Module Status LED | |
| Diagnostic Capabilities | Fault Detection and Reporting | |
| Operating Temperature Range | Standard Industrial Range (e.g., -40°C to +70°C) | |
| Humidity Range | 0 to 95% Non-Condensing (typical) | |
| Mounting | DeltaV Control Chassis Slot | |
| Primary Function | Multi-Purpose Discrete Signal Acquisition |
Application in Control and Monitoring Systems
You install this module to connect switches, sensors, and relay contacts to the DeltaV controller. It is ideal for monitoring equipment status, sequence logic, and safety interlock systems. The module’s robust construction and diagnostic features support high availability in demanding automation applications.
Details
| Weight | 0.2 kg |
|---|---|
| Dimensions | 150 × 100 × 50 mm |
