Overview
The 3500/61-01-00 from Bently Nevada is a temperature monitor module with recorder outputs. It accepts RTD and Thermocouple inputs, compares readings against programmable alarm setpoints, and outputs +4 to +20 mA signals for external recorders. This module ensures continuous and accurate temperature monitoring in industrial systems.
Key Features
- Supports 1 to 6 input channels for flexible temperature monitoring.
- Accepts RTD or Thermocouple signals for precise measurement.
- Provides independent +4 to +20 mA recorder outputs per channel.
- High input impedance of 10 MΩ minimizes signal loss.
- User-programmable alarm setpoints trigger real-time alerts.
- Short circuit protection ensures uninterrupted operation.
- Energy-efficient design with nominal 7-watt power consumption.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number | 3500/61-01-00 |
| Module Type | Temperature Monitor with Recorder Outputs |
| Input Channels | 1–6 channels |
| Input Signal Types | RTD (Resistance Temperature Detector), Thermocouple |
| Input Impedance | 10 MΩ |
| Alarm Setpoints | User-programmable |
| Recorder Outputs | +4 to +20 mA current loop per channel |
| Short Circuit Protection | Yes |
| Power Consumption | 7 Watts |
| Options | I/O Type: RTD/TC Non-isolated (01), Agency Approval: None (00) |
Applications
Bently Nevada 3500/61-01-00 is ideal for industrial systems requiring precise temperature monitoring with data logging. It integrates easily with chart recorders, data loggers, and other external devices.
Why Choose Bently Nevada 3500/61-01-00
This module provides accurate temperature measurement and reliable recorder outputs. Its high input impedance and short-circuit protection maintain system stability. Compact design and low power consumption enhance installation flexibility.
Details
| Weight | 0.1 kg |
|---|
