Precision Proximity Monitoring with Hazardous Area Certification
The Bently Nevada 3500/40-03-02 Proximitor Monitor provides highly accurate proximity measurement for rotating machinery in industrial environments. This module incorporates hazardous area approvals, allowing safe operation in locations with potentially explosive gases or dust. As part of the 3500 series, it delivers stable, reliable monitoring for predictive maintenance and machinery protection applications.
Key Features and Benefits
- Certified for ATEX, IECEx, and CSA hazardous area compliance (Class 1, Zone 2)
- Integrated I/O module with internal barriers and internal terminations for safe installation
- Compatible with 3500/40M Proximitor Monitors to provide accurate vibration and shaft position measurements
- Designed for high reliability, long-term operation, and minimal maintenance
- Supports modular installation into 3500 racks with convenient front or rear access
Configuration Details
- Model: 3500/40-03-02
- Series: 3500 Monitoring System
- Manufacturer: Bently Nevada
- I/O Type: Internal Barrier with Internal Termination
- Hazardous Area Approval: ATEX, IECEx, CSA
- Product Code: 176449-01
Technical Specifications
| Specification | Description |
|---|---|
| Module Type | Proximitor Monitor |
| Dimensions (Main Board) | 241.3 × 24.4 × 241.8 mm (9.50 × 0.96 × 9.52 in) |
| Weight (Main Board) | 0.91 kg (2.0 lb) |
| Dimensions (I/O Module) | 241.3 × 24.4 × 163.1 mm (9.50 × 0.96 × 6.42 in) |
| Weight (I/O Module) | 0.46 kg (1.01 lb) |
| Input Type | Proximity Probe and Proximitor Signal |
| Output | 4–20 mA proportional output or buffered signal |
| Power Requirement | 24 VDC supplied via rack |
| Operating Temperature | 0°C to +65°C |
| Rack Mounting | Full compatibility with 3500 series rack slots |
| Communication Interface | System bus and configuration via 3500 rack software |
| Hazardous Area Certification | ATEX, IECEx, CSA, Class 1 Zone 2 |
Performance and Applications
The 3500/40-03-02 monitor excels in measuring shaft vibration, axial position, and speed in turbines, compressors, and pumps. Its hazardous area certification ensures safety and compliance in explosive environments, while the internal barrier design simplifies installation. Engineers use this monitor to maintain machinery reliability, reduce unplanned downtime, and support predictive maintenance programs.
Physical Characteristics
- Main Board Weight: 0.91 kg (2.0 lb)
- I/O Module Weight: 0.46 kg (1.01 lb)
- Main Board Dimensions: 241.3 × 24.4 × 241.8 mm
- I/O Module Dimensions: 241.3 × 24.4 × 163.1 mm
Product Origin
- Manufactured in: USA
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 241.3 × 24.4 × 241.8 mm |
