The Bently Nevada 3500/15-07-07-00 Power Supply Module provides stable low-voltage DC power to the 3500 Series Monitoring System. Designed for continuous industrial operation, it ensures reliable performance for vibration and condition monitoring equipment. Both the top and bottom slots use low-voltage DC power inputs, offering consistent energy delivery and system protection.
Product Overview
The 3500/15-07-07-00 features dual Low Voltage DC power supply configuration, enabling redundancy and uninterrupted monitoring. This design supports mission-critical operations in turbines, compressors, and rotating machinery systems, maintaining optimal functionality even under demanding plant conditions.
The module installs easily into the 3500 rack and connects seamlessly with other Bently Nevada components, including monitors, communication modules, and interface cards. Its durable build and efficient cooling design enhance system longevity and reduce maintenance requirements.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 3500/15-07-07-00 |
| Series | 3500 Series |
| Manufacturer | Bently Nevada |
| Power Supply Type (Top Slot) | 07 = Low Voltage DC Supply |
| Power Supply Type (Bottom Slot) | 07 = Low Voltage DC Supply |
| Agency Approval | 00 = None |
| Voltage Range | 18–36 VDC |
| Maximum Power Output | 100 W |
| Efficiency | ≥ 85% |
| Operating Temperature | -30°C to +65°C |
| Cooling Method | Convection Cooling |
| Interface | Backplane connector for 3500 rack |
| Dimensions | 24.4 cm (H) × 2.5 cm (W) × 24.1 cm (D) |
| Weight | Approx. 0.8 kg |
| Installation Type | Rack-mounted |
| Redundancy | Dual Power Supply Capable |
Design and Functionality
The Bently Nevada 3500/15-07-07-00 ensures stable power delivery to monitoring modules across the rack. Its compact design supports redundant configuration, allowing one power module to take over instantly if the other fails. This redundancy enhances system reliability and protects connected sensors and processors from voltage fluctuations.
With robust internal components, the module minimizes energy loss and maintains consistent efficiency. Its modular structure enables quick replacement and expansion, reducing downtime during system maintenance.
Origin, Dimensions & Weight
- Origin: Made in U.S.A
- Dimensions: 24.4 × 2.5 × 24.1 cm
- Weight: Approximately 0.8 kg
Details
| Weight | 0.8 kg |
|---|---|
| Dimensions | 244 × 250 × 241 mm |
