Overview
The Bently Nevada 330425-01-05 Proximity Transducer System is designed for precise vibration monitoring, especially in critical machinery applications like gear mesh monitoring. With a high amplitude range of 75 g peak and 25 mV/g sensitivity, this system excels in applications requiring extensive measurement ranges.
The system offers excellent frequency response from 10 Hz to 15 kHz, making it suitable for a wide array of industrial monitoring needs. With features like a broad acceleration range and low noise floor, this proximity transducer is ideal for machinery that requires continuous, real-time monitoring to prevent failure and improve operational efficiency.
Key Features
- Sensitivity: 25 mV/g for high precision in vibration measurement.
- Acceleration Range: Provides 735 m/s² (75 g) peak overall acceleration.
- Amplitude Linearity: Ensures accuracy with ±1% to 735 m/s² peak.
- Broadband Noise: Low noise floor of 0.098 m/s² (0.01 g) RMS within 10 Hz to 15 kHz.
- Frequency Response:
- 10 Hz to 15 kHz (600 cpm to 900,000 cpm) ±3dB
- 30 Hz to 10 kHz (1800 cpm to 600,000 cpm) ±10%
Technical Specifications
| Specification | Value |
|---|---|
| Sensitivity | 25 mV/g ±5% |
| Acceleration Range | 735 m/s² (75 g) peak |
| Amplitude Linearity | ±1% to 735 m/s² (75 g) peak |
| Broadband Noise Floor | 0.098 m/s² (0.01 g) RMS |
| Frequency Response | 10 Hz to 15 kHz (±3 dB) |
| Temperature Sensitivity | -11% to +3% |
| Transverse Sensitivity | Less than 5% of axial sensitivity |
| Base Strain Sensitivity (With Mounting Base) | 4.9 mm/s²/mstrain (0.0005 g/mstrain) |
| Operating Temperature | -55°C to +121°C (-67°F to +250°F) |
| Shock Survivability | 49,050 m/s² (5000 g) peak, max |
| IP Rating | IP68 (Dust-tight and watertight) |
Physical Dimensions
| Specification | Value |
|---|---|
| Weight | 100 g (3.5 oz) |
| Diameter | 23 mm (0.93 in) |
| Height | 59 mm (2.3 in) including stud |
| Mounting Torque | 4.1 N·m (3.0 ft·lb) |
| Connector | 3-pin MIL-C-5015 Receptacle |
| Case Material | 316L Stainless Steel |
Ordering Information
- Model: 330425-01-05
- Mounting Thread: ¼-28 UNF integral stud
- Agency Approval: Multiple approvals (CSA, ATEX, IECEx)
FAQ
Q: What is the sensitivity of this proximity transducer system?
A: The sensitivity of this system is 25 mV/g, which ensures precise vibration measurements.
Q: What is the frequency range of the system?
A: The system offers a frequency response of 10 Hz to 15 kHz, making it suitable for a wide range of industrial monitoring applications.
Q: How does the system perform in extreme temperatures?
A: The 330425-01-05 can operate in temperatures ranging from -55°C to +121°C (-67°F to +250°F), ensuring reliable performance in harsh conditions.
Q: What is the shock survivability of the system?
A: The system can withstand up to 49,050 m/s² (5000 g) peak shock, making it durable in environments with high mechanical stress.
Q: How quickly can I receive the Bently Nevada 330425-01-05 proximity transducer?
A: We offer 3-14 day shipping, depending on the order size, with DHL as our standard fast shipping method.
Details
| Weight | 0.1 kg |
|---|
