Reliable connectivity in harsh industrial environments. The armored cable is designed for Bently Nevada Seismic Transmitters, ensuring consistent vibration signal transmission.
Key Advantages
- Durable Armor: Protects against mechanical damage and environmental stress.
- Plug-and-Play: Works seamlessly with PLC, DCS, and SCADA systems.
- High-Quality Data: Delivers accurate vibration readings for monitoring and analysis.
- Maintenance-Friendly: No field configuration required.
Electrical Specifications
Sensitivity (Main Loop)
- 0–12.7 mm/s (0–0.5 in/s)
- 0–25.4 mm/s (0–1.0 in/s)
- 0–50.8 mm/s (0–2.0 in/s)
Other Electrical Parameters
- Excitation Voltage: 12–30 Vdc, current limited to 40 mA
- Settling Time: Less than 15 seconds to 2% of final value
- Frequency Response: 10 Hz–1 kHz (velocity), 1 Hz–10 kHz (acceleration)
- Output Bias: 2.5 V ± 0.1 V
- Full Scale: 147 m/s² (15 g peak acceleration)
Physical & Environmental Details
| Attribute | Specification |
|---|---|
| Weight | 131 g (4.62 oz) |
| Dimensions | Diameter: 25.4 mm (1.00 in), Height: 66.0 mm (2.60 in) |
| Case Material | 316L Stainless Steel |
| Connector | 3-pin MIL-C-5015, stainless steel |
| Mounting | 1/4-28 UNF, torque 4–7 N-m |
| Operating Temperature | -40°C to +85°C |
| Humidity Resistance | Rated 100% non-submerged humidity |
Ordering Information
- Part Number: 16710-32
- Cable Length: 32 feet (Option A)
This armored interconnect cable is ideal for vibration monitoring in industrial environments. It ensures reliable signal transmission even under harsh conditions.
Details
| Weight | 0.131 kg |
|---|
