Product Overview
The Bently Nevada 136188-01 Ethernet/RS232 Modbus I/O Module enables seamless communication between Bently Nevada 3500 series systems and external control or SCADA systems. This module supports both Ethernet and RS232/RS422 Modbus interfaces, ensuring reliable and efficient data transfer for continuous monitoring.
Key Features
- Dual Communication Options: Supports both Ethernet and RS232/RS422 Modbus interfaces for versatile communication.
- Low Power Consumption: Consumes only 5.0 watts of power, making it energy-efficient for extended use.
- Compact Design: Sized to fit in standard 3500 series racks, with dimensions of 241 mm x 24.4 mm x 99.1 mm (9.50 in x 0.96 in x 3.90 in).
- Wide Temperature Range: Operates in temperatures ranging from -30°C to +65°C (-22°F to +149°F), ensuring reliability in various environments.
- High Humidity Tolerance: Designed to operate in environments with up to 95% humidity, non-condensing.
- Easy Firmware Upgrade: Compatible with the 126M4118-01 Firmware Upgrade Kit, which allows older Communication Gateway modules to work with this new I/O module.
Technical Specifications
| Attribute | Details |
|---|---|
| Manufacturer | Bently Nevada |
| Part Number | 136188-01 |
| Power Consumption | 5.0 watts (typical) |
| Operating Temperature Range | -30°C to +65°C (-22°F to +149°F) |
| Storage Temperature Range | -40°C to +85°C (-40°F to +185°F) |
| Humidity | Up to 95%, non-condensing |
| Dimensions (H x W x D) | 241 mm x 24.4 mm x 99.1 mm (9.50 in x 0.96 in x 3.90 in) |
| Weight | 0.44 kg (0.96 lbs) |
| Additional Options | 126M4118-01 Firmware Upgrade Kit for older modules |
Applications
The 136188-01 I/O Module is designed for use with the Bently Nevada 3500 series systems, offering reliable data transfer for critical applications in industries that rely on continuous monitoring and control systems.
FAQ
Q1: What communication interfaces does the 136188-01 support?
The 136188-01 supports both Ethernet and RS232/RS422 Modbus interfaces, ensuring flexible communication options.
Q2: What is the power consumption of this I/O module?
This I/O module consumes only 5.0 watts of power, making it energy-efficient and suitable for long-term use.
Q3: Can I upgrade the firmware of the 136188-01 module?
Yes, you can upgrade the firmware using the 126M4118-01 Firmware Upgrade Kit, available separately.
Q4: What are the environmental limits for the 136188-01 module?
The module operates in temperatures from -30°C to +65°C and can withstand up to 95% humidity without condensation.
Q5: What should I do if I need to replace this module in an existing system?
Ensure the replacement module is compatible with your existing system. If needed, consider upgrading your firmware using the 126M4118-01 Firmware Upgrade Kit.
Details
| Weight | 0.44 kg |
|---|
