Product Overview

The 115M7750-01 is a high voltage DC power input module (PIM) designed for use with High Voltage DC Power Supplies.
It delivers reliable DC power to systems requiring high voltage inputs.
This module is essential for industrial monitoring systems that demand stable, continuous power.

Key Features

• Input Voltage: 88–140 Vdc
• Rack-Mounted Design: Half-height module, installed directly behind associated power supply
• Compact and Lightweight: Minimizes space while ensuring reliability
• Robust Industrial Use: Built to operate under harsh conditions

Technical Specifications

Dimensions & Weight

• Height: 120.7 mm (4.75 in)
• Width: 25.4 mm (1.0 in)
• Depth: 114.3 mm (4.5 in)
• Weight: 0.34 kg (0.75 lb)

Environmental Limits

• Operating Temperature: -30°C to +65°C (-22°F to +150°F)
• Storage Temperature: -40°C to +85°C (-40°F to +185°F)
• Humidity: Up to 95%, non-condensing

Applications

• High voltage DC input for industrial monitoring and machinery protection systems
• Provides stable power for critical Bently Nevada monitoring modules
• Ideal for use in power plants, refineries, and other industrial facilities requiring reliable high voltage DC power

This 115M7750-01 module ensures safe, consistent, and efficient power delivery for high voltage DC applications in industrial environments.
