The Bachmann MPC240 medical panel computer combines powerful Intel Core i processors with a 24-inch FHD LCD. It offers up to 16GB DDR3L memory, dual-view support, and medical-grade certifications for demanding healthcare applications.
Key Features of Bachmann MPC240
- Ultra-slim housing with antimicrobial cover and rubber feet
- 24-inch TFT LCD display with 1920×1080 resolution and 250 nits brightness
- Support for Intel Core i7, i5, i3, Celeron, and Pentium CPUs
- Two DDR3L SODIMM slots, expandable to 16GB system memory
- Built-in 2.0-megapixel camera for telemedicine and eHealthcare applications
- Optional UPS battery backup providing up to 40 minutes runtime
- EN60601-1 and CE certifications ensuring compliance with medical standards
Technical Specifications
| Item Category | Specifications |
|---|---|
| Manufacturer | Bachmann |
| Model | MPC240 |
| Display | 24″ TFT LCD, 1920×1080 FHD, 250 nits |
| CPU Support | Intel 4th Gen Core i7/i5/i3, Celeron, Pentium |
| Cache / Chipset | 3–4 MB L2 cache, Intel HM86 chipset |
| System Memory | Two DDR3L SODIMM slots, up to 16GB, DDR3L 1600 MHz |
| BIOS / PMU | UEFI BIOS, 4096KB Flash, ACPI 3.0, LAN boot, USB boot |
| Touch Screen | Optional Projective Capacitive panel |
| Proximity Sensor | Auto display off at user distance >100–110 cm |
| Storage Options | 2.5” HDD 500/750 GB+, 2.5” SSD 64/128 GB, M2-SATA SSD 64/128 GB |
| Networking | Gigabit Ethernet, WLAN module, Intel 7260 WLAN |
| I/O Ports | 4x USB 2.0, 4x USB 3.0, HDMI, audio jacks, RJ-45, SDXC reader |
| Camera | Integrated 2.0 MP |
| Power Supply | Medical-grade AC adapter, 100–240V input, 19V 135W output |
| UPS Option | Internal UPS battery backup, 40 minutes operation |
| Mounting | VESA mounting support, optional stand |
| Housing | Antimicrobial cover and chassis, rubber feet |
| Operating Temperature | 5°C to 40°C |
| Storage Temperature | -30°C to 60°C |
| Humidity (Operation) | 10–90 % non-condensing |
| Humidity (Storage) | 5–95 % with condensation |
| Certifications | EN60601-1, CE |
Application and Usage
The Bachmann MPC240 is ideal for eHealthcare, Point of Care, and telemedicine solutions. Its powerful Intel processors, high-resolution display, and optional touch panel provide seamless user experience in medical environments. With EN60601-1 compliance, integrated camera, and reliable UPS support, it ensures safe and efficient performance in hospitals and clinical facilities.
Details
| Weight | 1 kg |
|---|---|
| Dimensions | 610 × 422.5 × 35.22 mm |
