Reliable 10-Slot Backplane for Complex Control Systems

The Bachmann BS210 backplane provides a stable and reliable platform for up to ten modules, enabling smooth integration into PLC, DCS, and factory automation systems. Its robust architecture ensures secure connections and consistent signal integrity across all modules, which is essential for high-speed industrial operations.

Advanced Electrical and Mechanical Design

The BS210 operates at 24V DC and withstands shocks up to 40g, ensuring stable performance even in harsh factory conditions. Moreover, it features high-quality connectors that maintain reliable data and power transmission for all connected modules. Its aluminum construction reduces weight while providing structural rigidity for long-term use.

Environmental and Operational Resilience

This backplane works in temperatures from -20°C to 70°C and tolerates storage conditions ranging from -40°C to 85°C. Furthermore, its non-condensing humidity range of 5–95% allows consistent performance in varying industrial environments. With a mean time between failures (MTBF) of 1,000,000 hours, the BS210 ensures high operational uptime.

Technical Specifications

Design Advantages and Applications

The compact and lightweight BS210 backplane simplifies cabinet layout while supporting multiple modules in demanding industrial applications. Moreover, its passive cooling design eliminates the need for additional fans, reducing maintenance requirements. The Bachmann BS210 is ideal for industrial automation, process control, and machine control systems where reliability and precision are critical.

Origin, Dimensions, and Weight

• Origin: Austria
• Dimensions: 55 × 11.8 × 2 cm
• Weight: 0.86 kg
