The Bachmann BS205 is a compact and reliable backplane designed for industrial automation applications. It supports up to five I/O modules, providing a stable connection for data and power distribution. Its robust construction ensures consistent performance across a wide temperature range, making it ideal for demanding industrial environments.
Key Features
- Supports up to 5 I/O modules for versatile system expansion
- 96-pin connectors deliver stable data and power signals
- Operates reliably between –20°C and +60°C for industrial environments
- DIN rail mountable for flexible and secure installation
- Compatible with multiple Bachmann I/O modules, including the BIO series
- Lightweight design at 180 g enables easy handling and installation
- Supports 24 V DC power supply for connected modules
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | BS205 |
| Manufacturer | Bachmann |
| Product Type | Backplane |
| Slot Capacity | Up to 5 I/O modules |
| Connector Type | 96-pin for data and power |
| Input Voltage | 24 V DC |
| Operating Temperature | –20°C to +60°C |
| Mounting | DIN rail mountable |
| Dimensions (L × W × H) | 176 × 85 × 35 mm |
| Weight | 180 g |
| Compatibility | Bachmann I/O modules, including BIO series |
Installation Guidelines
- Mount the BS205 backplane securely on a standard DIN rail.
- Connect 24 V DC power and ensure all modules are seated properly.
- Verify all connections are tight before powering the system.
Origin, Dimensions, and Weight
- Country of Origin: USA
- Dimensions: 176 × 85 × 35 mm
- Weight: 180 g
Applications
The Bachmann BS205 serves as a reliable backbone for industrial I/O systems, enabling secure module connections and consistent power delivery in automation setups. Its compact, lightweight design and broad compatibility make it suitable for diverse industrial environments.
Details
| Weight | 0.18 kg |
|---|---|
| Dimensions | 176 × 85 × 35 mm |
