The Allen-Bradley 1794-IB16XOB16P is a high-performance Flex I/O DC Input/Output Module designed for industrial automation systems. It offers 16 sinking inputs and 16 sourcing outputs with a 24V DC power supply. The module ensures efficient data transmission through Ethernet TCP/IP and supports both 2-wire and 4-wire systems. It mounts easily on DIN-rails or panels and integrates seamlessly with PLC systems.
Key Features
- Open-style module with compact industrial design
- Access data via standard network card and Ethernet LAN
- Compatible with AC500 series PLCs and peripheral equipment
- Designed for central control room operation
- Mounts on 1794-TB32 or 1794-TB32S terminal bases
- European Zone 2 Certification with EEx marking
- North American Hazardous Location approval
Technical Specifications
| Specification | Details |
|---|---|
| Brand | Allen-Bradley / Rockwell Automation |
| Series | Flex I/O 1794 |
| Part Number | 1794-IB16XOB16P |
| Class | Programmable Logic Controller Module |
| Input | 16-point 24V DC sinking |
| Output | 16-point 24V DC sourcing |
| Power Supply | 24V DC |
| Maximum Wattage | 125W |
| Number of Channels | 32-point |
| Mounting | DIN-rail, Panel |
| Special Features | Electronically Protected |
| NEMA Rating | IP20 |
| UPC | 10612598279897 |
Revisions
- 1794-IB16XOB16P/A: Series A, Revision A
Applications
The 1794-IB16XOB16P is ideal for centralized industrial control, process automation, and distributed I/O systems requiring reliable DC input/output performance. It supports high-speed communication and protects against electrical faults.
More Information
Full technical documentation: Allen-Bradley 1794 Flex I/O Manual
Details
| Weight | 0.098 kg |
|---|---|
| Dimensions | 94 × 94 × 69 mm |
