Product Description
The Allen-Bradley 1769-L36ERMS CompactLogix 5370 L3 controller combines integrated safety, motion, and communication into a single platform. It supports up to 32 tasks and 100 programs per task, ensuring robust and flexible control for complex automation environments. Moreover, its dual Ethernet ports with an embedded switch allow seamless communication between EtherNet/IP networks and connected devices.
This controller is ideal for machine-level applications requiring deterministic safety performance and advanced motion control. With its compact design, it fits easily into space-limited control panels while maintaining powerful processing capability.
Functional Highlights
The 1769-L36ERMS enhances automation performance through advanced networking, embedded I/O, and flexible communication interfaces. For instance, it supports 16 axes of integrated motion over EtherNet/IP, making it suitable for coordinated multi-axis applications.
In addition, it includes embedded safety control, allowing standard and safety tasks to coexist in one processor without external hardware. Its built-in diagnostic tools and alarm handling improve system reliability and reduce commissioning time.
Key Benefits:
✔ Dual Ethernet ports with embedded switch
✔ Supports 48 EtherNet/IP nodes and 256 controller connections
✔ Up to 32 tasks and 100 programs per task
✔ 30 Compact I/O modules supported with up to 3 banks
✔ Integrated motion and safety in one platform
✔ DIN rail or panel mounting for installation flexibility
Technical Specifications
| Parameter | Details |
|---|---|
| Processor Type | CompactLogix 5370 L3 |
| Ethernet Ports | 2 ports (shared IP) |
| USB Port | 1 (temporary connection) |
| User Memory | Supports up to 30 Compact I/O modules |
| Max I/O Banks | 3 |
| Embedded I/O | 16 DC inputs, 16 DC outputs, 4 analog inputs, 2 analog outputs |
| Integrated Motion | Up to 16 EtherNet/IP axes |
| Current Draw @24VDC | 700 mA |
| Power Dissipation | 6.5 W |
| Operating Temperature | 0–60°C (32–140°F) |
| Storage Temperature | -40–85°C (-40–185°F) |
| Vibration | 5 g (10–500 Hz) |
| Shock | 20 g operational (DIN rail), 30 g non-operational |
| Isolation Voltage | 50V Basic Insulation |
| Mounting | DIN rail or panel mount |
| Compatible Power Supplies | 1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4 |
Furthermore, the controller meets IEC 60068 and IEC 61000 immunity standards, providing reliable operation in industrial conditions.
System Integration & Applications
The 1769-L36ERMS seamlessly integrates with ControlLogix, Compact I/O, and Kinetix motion drives, making it an ideal choice for mixed-control environments. For instance, it can manage process automation, safety logic, and machine motion simultaneously.
Therefore, it is widely applied in packaging machines, material handling, robotic assembly lines, and safety-critical production cells. Its safety integrity and EtherNet/IP scalability ensure both high throughput and compliance with global safety standards.
