Product Overview
The Allen-Bradley 1769-L30 CompactLogix™ Controller actively provides reliable and flexible control for industrial automation systems. Moreover, it supports up to 16 I/O modules across 3 banks, enabling efficient and scalable system integration. In addition, its compact design and robust performance make it suitable for a wide range of industrial applications.
Key Features
- Controller Model: 1769-L30
- Communication Ports: 2 RS-232 ports for programming and device connectivity
- User Memory: 256K bytes for application programs
- Maximum I/O Modules: 16 modules
- Maximum I/O Banks: 3 banks
- Power Supply Distance Rating: 4 slots from the power supply
- Battery: 1747-BA (Sanyo CR14250SE)
Technical Specifications
| Specification | Details |
|---|---|
| Operating Temperature | 0° to +60°C (+32° to +140°F) |
| Storage Temperature | -40° to +85°C (-40° to +185°F) |
| Relative Humidity | 5% to 95% non-condensing |
| Backplane Current | 800 mA at +5V DC, 0 mA at +24V DC |
| Vibration Resistance | Operating: 10–500 Hz, 5G, 0.030 in. peak-to-peak |
| Non-operating Shock | Panel mounted: 40G; DIN rail mounted: 30G |
| Shipping Weight | 360 g (0.792 lbs) |
| Programming Cable | 1747-CP3 or 1756-CP3 |
| Agency Certifications | C-UL (CSA C22.2 No.142), UL 508, CE compliant |
| Hazardous Environment | Class I, Division 2, Groups A-D (UL 1604, CSA C22.2 No.213) |
| EMC Compliance | EN50081-2 Class A; ESD IEC61000-4-2: 4 kV contact, 8 kV air, 4 kV indirect |
| Immunity | Radiated IEC61000-4-3: 10 V/m, 80–1000 MHz; Fast Transient IEC61000-4-4: 2 kV |
| Surge & Conducted | Surge IEC61000-4-5: 1 kV; Conducted IEC61000-4-6: 10 V, 0.15–80 MHz |
System Integration & Applications
The 1769-L30 actively integrates with CompactLogix™ I/O modules to control industrial processes efficiently. Therefore, engineers can deploy it in manufacturing, packaging, or process automation systems. Moreover, its EMC and hazardous environment compliance ensures reliable operation in challenging industrial conditions. As a result, this controller provides high reliability, robust performance, and seamless integration for complex automation networks.
FAQ
- Is this controller new and original? Yes, Allen-Bradley supplies it factory-new and fully genuine.
- How fast can it be shipped? Stock is generally available; delivery occurs within 3 days to 2 weeks depending on order size. DHL and other carriers are supported.
- What if there is a quality issue? Returns are accepted within 30 days for manufacturing defects.
Details
| Weight | 0.36 kg |
|---|
