Compact Controller with Ethernet and Analog Capabilities
The Allen-Bradley 1763-L16AWA combines digital and analog I/O with built-in Ethernet, delivering versatile control solutions. Moreover, it supports RS-232/485 communication and an integrated LCD, enabling remote monitoring and local programming. Consequently, operators can manage small to medium automation systems efficiently.
Key Technical Specifications
| Specification | Details |
|---|---|
| Brand & Series | Allen-Bradley MicroLogix 1100 |
| Model | 1763-L16AWA Controller |
| Input Power | 120–240V AC |
| Power Consumption | 46 VA |
| Digital Inputs | 12 points, 120V AC |
| Analog Inputs | 2 channels, 0–10V DC, 10-bit resolution |
| Relay Outputs | 6 points, 10A @ 120–240V AC |
| Relay Contact Life | 10 million cycles |
| Communication Ports | Ethernet 10/100 Mbps, RS-232/485 combo |
| Embedded Display | LCD for configuration and monitoring |
| Web Server Capability | Built-in, supports remote monitoring |
| Operating Temperature | 0°C to 55°C |
| Dimensions | 8.89 x 11.0 x 8.7 cm (3.5 x 4.33 x 3.43 in) |
| Weight | 0.9 kg (2 pounds) |
Installation and Setup
First, mount the 1763-L16AWA on a DIN rail inside an industrial enclosure. Then, connect digital and analog I/O, Ethernet, and RS-232/485 ports for full system integration. Next, configure settings using the built-in LCD or compatible software. Consequently, this approach ensures rapid deployment and operational efficiency.
Packaging and Shipping
The Allen-Bradley 1763-L16AWA comes with complete installation and programming documentation. Moreover, we ship globally via FedEx, UPS, and DHL with anti-static packaging. Fast order processing ensures delivery within 1–3 business days.
Warranty and Technical Support
This controller includes a 12-month full warranty. In addition, our technical support team provides guidance on configuration, program backup, and troubleshooting. As a result, customers receive reliable support for mission-critical automation tasks.
Frequently Asked Questions
Which communication ports are available?
The controller features a built-in Ethernet port and RS-232/485 combo port for versatile connectivity.
Can I monitor the controller remotely?
Yes, the embedded web server allows full remote monitoring and system control.
What is the resolution of analog inputs?
The two analog inputs provide 10-bit resolution, offering 1024 steps for precise measurements.
How many relay outputs exist?
Six relay outputs handle loads up to 10A at 120–240V AC for various devices.
Which industries commonly use this controller?
The controller suits material handling, food processing, packaging, water treatment, and general machinery automation.
Origin: United States
Dimensions & Weight: 8.89 x 11.0 x 8.7 cm, 0.9 kg
