Overview: High-Performance Processor for Industrial Automation
The Allen-Bradley 1756-L82EP from the ControlLogix 5580 series delivers superior performance for complex industrial applications. Moreover, it supports 5MB of user memory and high-speed gigabit Ethernet communication. In addition, the processor manages up to 128,000 digital I/O points, enabling large-scale factory automation systems with demanding control requirements.
Key Features
- High-speed 10/100/1000 Mbps Ethernet and 12 Mbps USB Type-B interface
- Handles 128,000 digital I/O points and 4,000 analog I/O points
- Supports 32 simultaneous tasks with up to 1,000 programs per task
- Integrated motion control over Ethernet for precise automation
- Low power dissipation of 6.2 Watts (21.2 BTU/hour)
- Single-slot installation compatible with standard 1756 ControlLogix chassis
- Programming support: Ladder Logic, Structured Text, Function Block, Sequential Function Chart
Technical Specifications
| Parameter | Details |
|---|---|
| Brand | Allen-Bradley / Rockwell Automation |
| Model | 1756-L82EP |
| Series | ControlLogix 5580 |
| Product Type | Processor Module |
| User Memory | 5 MB |
| Ethernet Speed | 10/100/1000 Mbps |
| USB Speed | 12 Mbps (Type B) |
| Digital I/O Capacity | 128,000 points |
| Analog I/O Capacity | 4,000 points |
| Controller Tasks | 32 maximum |
| Programs per Task | 1,000 |
| Power Dissipation | 6.2 W |
| Thermal Dissipation | 21.2 BTU/hour |
| Current Draw | 1.20A @ 5.1V DC / 5.0mA @ 1.2V DC |
| Slot Requirement | Single slot |
| Network Compatibility | EtherNet/IP, ControlNet, DeviceNet, Remote I/O, Data Highway Plus, SynchLink |
| Programming Languages | Ladder Logic, Structured Text, Function Block Diagram, Sequential Function Chart |
Physical Details
- Dimensions: 50 mm x 120 mm x 180 mm
- Weight: 0.394 kg (0.868 lbs)
- Country of Origin: USA
Installation & Network Integration
Installing the 1756-L82EP is simple and requires only a single slot. Furthermore, it integrates seamlessly with ControlLogix 5580 chassis. In addition, the processor communicates reliably across EtherNet/IP, ControlNet, DeviceNet, and Remote I/O networks.
Applications & Use Cases
- Large-scale industrial automation systems with high I/O demands
- Motion control applications requiring precise, synchronized operations
- Factory automation environments requiring high-speed network integration
- Process control systems managing complex tasks and programs
Quality & Warranty
The 1756-L82EP comes with complete documentation and a 12-month manufacturer warranty. Moreover, we provide fast worldwide shipping via FedEx, UPS, and DHL, ensuring reliable delivery for global customers.
